Daikin 2MXS40H2V1B [23/32] Capacity tables
![Daikin 2MXS40H2V1B [23/32] Capacity tables](/views2/1771726/page23/bg17.png)
• Split - Sky Air
®
• Outdoor Unit
21
• Outdoor Unit • Multi model application • MXS-H
4 Capacity tables
4 - 4 Heating Capacity Tables
2MXS50
★ Heating (50Hz 230V)
3D059196
Combination
(capacity)
outdoor
air temp.
Indoor air temp.: °CDB
16°C 18°C 20°C 21°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CWB kW kW kW kW kW kW kW kW kW kW kW kW
2.0+2.5 -15.0 3.21 1.26 3.13 1.28 3.05 1.29 3.01 1.30 2.97 1.30 2.89 1.32
-11.0 3.73 1.31 3.65 1.33 3.57 1.34 3.53 1.35 3.49 1.36 3.41 1.37
-8.0 4.13 1.35 4.05 1.37 3.97 1.38 3.93 1.39 3.89 1.39 3.81 1.41
-6.0 4.39 1.38 4.31 1.39 4.23 1.41 4.19 1.41 4.15 1.42 4.07 1.43
-1.0 5.04 1.44 4.96 1.46 4.88 1.47 4.84 1.48 4.80 1.48 4.72 1.50
1.0 5.31 1.47 5.23 1.48 5.15 1.50 5.11 1.50 5.06 1.51 4.98 1.52
3.0 5.57 1.49 5.49 1.51 5.41 1.52 5.37 1.53 5.33 1.54 5.25 1.55
6.0 5.96 1.53 5.88 1.55 5.80 1.56 5.76 1.57 5.72 1.57 5.64 1.59
8.0 6.22 1.56 6.14 1.57 6.06 1.59 6.02 1.59 5.98 1.60 5.90 1.61
10.0 6.48 1.58 6.40 1.60 6.32 1.61 6.28 1.62 6.24 1.63 6.16 1.64
12.0 6.75 1.61 6.67 1.62 6.59 1.+64 6.55 1.64 6.51 1.65 6.43 1.67
15.0 7.14 1.65 7.06 1.66 6.98 1.68 6.94 1.68 6.90 1.69 6.82 1.70
18.0 7.53 1.69 7.45 1.70 7.37 1.71 7.33 1.72 7.29 1.73 7.21 1.74
2.0+3.5 -15.0 3.26 1.27 3.18 1.28 3.10 1.30 3.06 1.31 3.02 1.31 2.94 1.33
-11.0 3.80 1.32 3.72 1.34 3.63 1.35 3.59 1.36 3.55 1.36 3.47 1.38
-8.0 4.20 1.36 4.12 1.37 4.03 1.39 3.99 1.40 3.95 1.40 3.87 1.42
-6.0 4.46 1.39 4.38 1.40 4.30 1.41 4.26 1.42 4.22 1.43 4.14 1.44
-1.0 5.13 1.45 5.05 1.47 4.97 1.48 4.93 1.49 4.89 1.49 4.80 1.51
1.0 5.40 1.48 5.32 1.49 5.23 1.51 5.19 1.51 5.15 1.52 5.07 1.53
3.0 5.66 1.50 5.58 1.52 5.50 1.53 5.46 1.54 5.42 1.55 5.34 1.56
6.0 6.06 1.54 5.98 1.56 5.90 1.57 5.86 1.58 5.82 1.58 5.74 1.60
8.0 6.33 1.57 6.25 1.58 6.17 1.60 6.13 1.60 6.09 1.61 6.00 1.62
10.0 6.60 1.59 6.51 1.61 6.43 1.62 6.39 1.63 6.35 1.64 6.27 1.65
12.0 6.86 1.62 6.78 1.63 6.70 1.65 6.66 1.65 6.62 1.66 6.54 1.68
15.0 7.26 1.66 7.18 1.67 7.10 1.69 7.06 1.69 7.02 1.70 6.94 1.71
18.0 7.66 1.70 7.58 1.71 7.50 1.73 7.46 1.73 7.42 1.74 7.34 1.75
2.0+4.2 -15.0 3.32 1.29 3.24 1.30 3.15 1.32 3.11 1.32 3.07 1.33 2.99 1.34
-11.0 3.86 1.34 3.78 1.35 3.70 1.37 3.66 1.37 3.61 1.38 3.53 1.40
-8.0 4.27 1.38 4.19 1.39 4.10 1.41 4.06 1.41 4.02 1.42 3.94 1.44
-6.0 4.54 1.40 4.46 1.42 4.37 1.43 4.33 1.44 4.29 1.45 4.21 1.46
-1.0 5.22 1.47 5.13 1.48 5.05 1.50 5.01 1.51 4.97 1.51 4.89 1.53
1.0 5.49 1.50 5.41 1.51 5.32 1.52 5.28 1.53 5.24 1.54 5.16 1.55
3.0 5.76 1.52 5.68 1.54 5.59 1.55 5.55 1.56 5.51 1.57 5.43 1.58
6.0 6.17 1.56 6.08 1.58 6.00 1.59 5.96 1.60 5.92 1.60 5.83 1.62
8.0 6.44 1.59 6.35 1.60 6.27 1.62 6.23 1.62 6.19 1.63 6.11 1.64
10.0 6.71 1.61 6.62 1.63 6.54 1.64 6.50 1.65 6.46 1.66 6.38 1.67
12.0 6.98 1.64 6.90 1.65 6.81 1.67 6.77 1.68 6.73 1.68 6.65 1.70
15.0 7.39 1.68 7.30 1.69 7.22 1.73 7.18 1.72 7.14 1.72 7.05 1.74
18.0 7.79 1.72 7.71 1.73 7.63 1.75 7.58 1.75 7.54 1.76 7.46 1.78
Combinasion
(Capacity)
outdoor
air temp.
Indoor air temp.: °CDB
16°C 18°C 20°C 21 C 22 C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CWB kW kW kW kW kW kW kW kW kW kW kW kW
2.0+5.0 -15.0 3.43 1.30 3.35 1.32 3.26 1.33 3.22 1.34 3.17 1.35 3.09 1.36
-11.0 3.99 1.36 3.91 1.37 3.82 1.38 3.78 1.39 3.73 1.40 3.65 1.41
-8.0 4.41 1.40 4.33 1.41 4.24 1.42 4.20 1.43 4.15 1.44 4.07 1.45
-6.0 4.69 1.42 4.61 1.44 4.52 1.45 4.48 1.46 4.43 1.47 4.35 1.48
-1.0 5.39 1.49 5.31 1.50 5.22 1.52 5.18 1.52 5.13 1.53 5.05 1.55
1.0 5.67 1.51 5.59 1.53 5.50 1.54 5.46 1.55 5.41 1.56 5.33 1.57
3.0 5.95 1.54 5.87 1.56 5.78 1.57 5.74 1.58 5.69 1.58 5.61 1.60
6.0 6.37 1.58 6.29 1.60 6.20 1.61 6.16 1.62 6.11 1.62 6.03 1.64
8.0 6.65 1.61 6.57 1.62 6.48 1.64 6.44 1.64 6.39 1.65 6.31 1.67
10.0 6.93 1.63 6.85 1.65 6.76 1.66 6.72 1.67 6.67 1.68 6.59 1.69
12.0 7.21 1.66 7.13 1.68 7.04 1.69 7.00 1.70 6.95 1.70 6.87 1.72
15.0 7.63 1.70 7.55 1.71 7.46 1.73 7.42 1.74 7.37 1.74 7.29 1.76
18.0 8.05 1.74 7.97 1.75 7.88 1.77 7.84 1.78 7.79 1.78 7.71 1.80
2.5+2.5 -15.0 3.21 1.25 3.13 1.27 3.05 1.28 3.01 1.29 2.97 1.30 2.89 1.31
-11.0 3.73 1.31 3.65 1.32 3.57 1.33 3.53 1.34 3.49 1.35 3.41 1.36
-8.0 4.13 1.34 4.05 1.36 3.97 1.37 3.93 1.38 3.89 1.39 3.81 1.40
-6.0 4.39 1.37 4.31 1.38 4.23 1.40 4.19 1.40 4.15 1.41 4.07 1.42
-1.0 5.04 1.43 4.96 1.45 4.88 1.46 4.84 1.47 4.80 1.47 4.72 1.49
1.0 5.31 1.46 5.23 1.47 5.15 1.49 5.11 1.49 5.06 1.50 4.98 1.51
3.0 5.57 1.48 5.49 1.50 5.41 1.51 5.37 1.52 5.33 1.53 5.25 1.54
6.0 5.96 1.52 5.88 1.54 5.80 1.55 5.76 1.56 5.72 1.56 5.64 1.58
8.0 6.22 1.55 6.14 1.56 6.06 1.58 6.02 1.58 5.98 1.59 5.90 1.60
10.0 6.48 1.57 6.40 1.59 6.32 1.60 6.28 1.61 6.24 1.62 6.16 1.63
12.0 6.75 1.60 6.67 1.61 6.59 1.63 6.55 1.63 6.51 1.64 6.43 1.65
15.0 7.14 1.64 7.06 1.65 6.98 1.66 6.94 1.67 6.90 1.68 6.82 1.69
18.0 7.53 1.68 7.45 1.69 7.37 1.70 7.33 1.71 7.29 1.72 7.21 1.73
2.5+3.5 -15.0 3.32 1.33 3.24 1.34 3.15 1.36 3.11 1.36 3.07 1.37 2.99 1.39
-11.0 3.86 1.38 3.78 1.40 3.70 1.41 3.66 1.42 3.61 1.43 3.53 1.44
-8.0 4.27 1.42 4.19 1.44 4.10 1.45 4.06 1.46 4.02 1.47 3.94 1.48
-6.0 4.54 1.45 4.46 1.46 4.37 1.48 4.33 1.49 4.29 1.49 4.21 1.51
-1.0 5.22 1.52 5.17 1.53 5.05 1.55 5.01 1.55 4.97 1.56 4.89 1.58
1.0 5.49 1.54 5.41 1.56 5.32 1.57 5.28 1.58 5.24 1.59 5.16 1.60
3.0 5.76 1.57 5.68 1.58 5.59 1.60 5.55 1.61 5.51 1.61 5.43 1.63
6.0 6.17 1.61 6.08 1.63 6.0 1.64 5.96 1.65 5.92 1.65 5.83 1.67
8.0 6.44 1.64 6.35 1.65 6.27 1.67 6.23 1.67 6.19 1.68 6.11 1.70
10.0 6.71 1.66 6.62 1.68 6.54 1.69 6.50 1.70 6.46 1.71 6.38 1.72
12.0 6.98 1.69 6.90 1.71 6.81 1.72 6.77 1.73 6.73 1.74 6.65 1.75
15.0 7.39 1.73 7.30 1.75 7.22 1.76 7.18 1.77 7.14 1.78 7.05 1.79
18.0 7.79 1.77 7.71 1.79 7.63 1.80 7.58 1.81 7.54 1.82 7.46 1.83
SYMBOLS
TC: Total capacity (kW)
PI: Power input (kW)
NOTE
1 Capacities are based on the following conditions.
Corresponding refrigerant piping length: 5m
Level difference: 0m
2 The bold line is indicated the standard condition.
3 The above is the value for connecting with the following indoor units.
2.0, 2.5, 3.5, 4.2, 5.0 kW Class; wall mounted series.
