Daikin 2MXS40H2V1B [22/32] Capacity tables
![Daikin 2MXS40H2V1B [22/32] Capacity tables](/views2/1771726/page22/bg16.png)
• Outdoor Unit • Multi model application • MXS-H
• Split - Sky Air
®
• Outdoor Unit
20
4 Capacity tables
4 - 4 Heating Capacity Tables
2MXS50
★ Heating (50Hz 230V)
3D059195
Combination
(capacity)
outdoor
air temp.
Indoor air temp.: °CDB
16°C 18°C 20°C 21°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CWB kW kW kW kW kW kW kW kW kW kW kW kW
2.0 -15.0 2.05 0.92 2.00 0.93 1.95 0.94 1.92 0.95 1.89 0.95 1.84 0.96
-11.0 2.38 0.96 2.33 0.97 2.28 0.98 2.25 0.99 2.23 0.99 2.18 1.00
-8.0 2.63 0.99 2.58 1.00 2.53 1.01 2.50 1.01 2.48 1.02 2.43 1.03
-6.0 2.80 1.01 2.75 1.02 2.70 1.03 2.67 1.03 2.65 1.04 2.60 1.05
-1.0 3.22 1.05 3.17 1.06 3.12 1.07 3.09 1.08 3.06 1.08 3.01 1.09
1.0 3.38 1.07 3.33 1.08 3.28 1.09 3.26 1.10 3.23 1.10 3.18 1.11
3.0 3.55 1.09 3.50 1.10 3.45 1.11 3.42 1.12 3.40 1.12 3.35 1.13
6.0 3.80 1.12 3.75 1.13 3.70 1.14 3.67 1.15 3.65 1.15 3.60 1.16
8.0 3.97 1.14 3.92 1.15 3.87 1.16 3.84 1.16 3.82 1.17 3.76 1.18
10.0 4.14 1.16 4.09 1.17 4.03 1.18 4.01 1.18 3.98 1.19 3.93 1.20
12.0 4.30 1.18 4.25 1.19 4.20 1.20 4.18 1.20 4.15 1.21 4.10 1.22
15.0 4.55 1.20 4.50 1.21 4.45 1.22 4.43 1.23 4.40 1.23 4.35 1.25
18.0 4.80 1.23 4.75 1.24 4.70 1.25 4.68 1.26 4.65 1.26 4.60 1.27
2.5 -15.0 2.27 1.08 2.21 1.09 2.16 1.10 2.13 1.11 2.10 1.11 2.04 1.12
-11.0 2.64 1.12 2.58 1.13 2.53 1.14 2.50 1.15 2.47 1.16 2.41 1.17
-8.0 2.92 1.15 2.86 1.16 2.80 1.18 2.78 1.18 2.75 1.19 2.69 1.20
-6.0 3.10 1.17 3.05 1.19 2.99 1.20 2.96 1.20 2.93 1.21 2.88 1.22
-1.0 3.57 1.23 3.51 1.24 3.45 1.25 3.42 1.26 3.40 1.27 3.34 1.28
1.0 3.75 1.25 3.69 1.26 3.64 1.28 3.61 1.28 3.58 1.29 3.52 1.30
3.0 3.94 1.27 3.88 1.29 3.82 1.30 3.79 1.30 3.77 1.31 3.71 1.32
6.0 4.21 1.31 4.16 1.32 4.10 1.33 4.07 1.34 4.04 1.34 3.99 1.35
8.0 4.40 1.33 4.34 1.34 4.29 1.35 4.26 1.36 4.23 1.36 4.17 1.38
10.0 4.58 1.35 4.53 1.36 4.47 1.37 4.44 1.38 4.41 1.39 4.36 1.40
12.0 4.77 1.37 4.71 1.38 4.66 1.40 4.63 1.40 4.60 1.41 4.54 1.42
15.0 5.05 1.40 4.99 1.42 4.93 1.43 4.91 1.43 4.88 1.44 4.59 1.35
18.0 5.32 1.44 5.27 1.45 5.17 1.44 5.02 1.40 4.88 1.35 4.59 1.27
3.5 -15.0 2.55 1.24 2.48 1.25 2.42 1.27 2.39 1.27 2.35 1.28 2.29 1.29
-11.0 2.96 1.29 2.90 1.30 2.83 1.32 2.80 1.32 2.77 1.33 2.71 1.34
-8.0 3.27 1.33 3.21 1.34 3.15 1.35 3.11 1.36 3.08 1.37 3.02 1.38
-6.0 3.448 1.35 3.42 1.37 3.35 1.38 3.32 1.39 3.29 1.39 3.23 1.41
-1.0 4.00 1.41 3.94 1.43 3.87 1.44 3.84 1.45 3.81 1.46 3.75 1.47
1.0 4.21 1.44 4.14 1.45 4.08 1.47 4.05 1.47 4.02 1.48 3.95 1.49
3.0 4.42 1.46 4.35 1.48 4.29 1.49 4.26 1.50 4.22 1.51 4.16 1.52
6.0 4.73 1.50 4.66 1.52 4.60 1.53 4.57 1.54 4.54 1.54 4.47 1.56
8.0 4.93 1.53 4.87 1.54 4.81 1.56 4.78 1.56 4.74 1.57 4.68 1.58
10.0 5.14 1.55 5.08 1.57 5.02 1.58 4.98 1.59 4.95 1.59 4.74 1.53
12.0 5.35 1.58 5.29 1.59 5.22 1.61 5.18 1.61 5.04 1.56 4.74 1.46
15.0 5.66 1.62 5.60 1.63 5.33 1.55 5.18 1.50 5.04 1.45 4.74 1.36
18.0 5.93 1.63 5.63 1.54 5.33 1.45 5.18 1.41 5.04 1.36 4.74 1.27
Combinasion
(Capacity)
outdoor
air temp.
Indoor air temp.: °CDB
16°C 18°C 20°C 21 C 22 C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CWB kW kW kW kW kW kW kW kW kW kW kW kW
4.2 -15.0 2.82 1.43 2.75 1.45 2.68 1.46 2.65 1.47 2.61 1.48 2.54 1.50
-11.0 3.28 1.49 3.21 1.51 3.14 1.52 3.11 1.53 3.07 1.54 3.00 1.55
-8.0 3.63 1.53 3.56 1.55 3.49 1.57 3.45 1.57 3.42 1.58 3.35 1.60
-6.0 3.86 1.56 3.79 1.58 3.72 1.60 3.68 1.60 3.65 1.61 3.58 1.63
-1.0 4.43 1.64 4.36 1.65 4.29 1.67 4.26 1.68 4.22 1.68 4.15 1.70
1.0 4.66 1.67 4.59 1.68 4.52 1.70 4.49 1.71 4.45 1.71 4.38 1.73
3.0 4.90 1.69 4.82 1.71 4.75 1.73 4.72 1.73 4.68 1.74 4.61 1.76
6.0 5.24 1.74 5.17 1.75 5.10 1.77 5.06 1.78 5.03 1.79 4.74 1.67
8.0 5.47 1.77 5.40 1.78 5.33 1.80 5.18 1.74 5.04 1.69 4.74 1.58
10.0 5.70 1.80 5.63 1.81 5.33 1.70 5.18 1.65 5.04 1.60 4.74 1.49
12.0 5.93 1.82 5.63 1.72 5.33 1.62 5.18 1.57 5.04 1.52 4.74 1.42
15.0 5.93 1.70 5.63 1.60 5.33 1.51 5.18 1.46 5.04 1.41 4.74 1.32
18.0 5.93 1.59 5.63 1.50 5.33 1.41 5.18 1.37 5.04 1.33 4.74 1.24
5.0 -15.0 3.10 1.60 3.02 1.62 2.94 1.64 2.91 1.65 2.87 1.66 2.79 1.67
-11.0 3.60 1.67 3.53 1.68 3.45 1.70 3.41 1.71 3.37 1.72 3.30 1.74
-8.0 3.98 1.72 3.91 1.73 3.83 1.75 3.79 1.76 3.75 1.77 3.67 1.79
-6.0 4.24 1.75 4.16 1.77 4.08 1.78 4.04 1.79 4.01 1.80 3.93 1.82
-1.0 4.87 1.83 4.79 1.85 4.71 1.87 4.68 1.87 4.64 1.88 4.56 1.90
1.0 5.12 1.86 5.04 1.88 4.97 1.90 4.93 1.91 4.89 1.92 4.81 1.93
3.0 5.38 1.90 5.30 1.91 5.22 1.93 5.18 1.94 5.14 1.95 5.07 1.97
6.0 5.75 1.94 5.68 1.96 5.60 1.98 5.56 1.99 5.52 2.00 5.28 1.91
8.0 6.01 1.98 5.93 1.99 5.85 2.01 5.77 2.00 5.61 1.93 5.28 1.79
10.0 6.26 2.01 6.18 2.03 5.94 1.95 5.77 1.88 5.61 1.82 5.28 1.69
12.0 6.51 2.04 6.27 1.96 5.94 1.84 5.77 1.78 5.61 1.72 5.28 1.60
15.0 6.60 1.93 6.27 1.82 5.94 1.71 5.77 1.65 5.61 1.60 5.28 1.49
1.80 6.54 1.80 6.27 1.70 5.94 1.59 5.77 1.54 5.61 1.49 5.28 1.39
2.0+2.0 -15.0 3.15 1.24 3.08 1.25 3.00 1.27 2.96 1.27 2.92 1.28 2.84 1.29
-11.0 3.67 1.29 3.59 1.30 3.51 1.32 3.47 1.32 3.43 1.33 3.35 1.34
-8.0 4.06 1.33 3.98 1.34 3.90 1.35 3.86 1.36 3.82 1.37 3.74 1.38
-6.0 4.31 1.35 4.23 1.37 4.16 1.38 4.12 1.39 4.08 1.39 4.00 1.41
-1.0 4.96 1.41 4.88 1.43 4.80 1.44 4.76 1.45 4.72 1.46 4.64 1.47
1.0 5.21 1.44 5.14 1.45 5.06 1.47 5.02 1.47 4.98 1.48 4.90 1.49
3.0 5.47 1.46 5.39 1.48 5.31 1.49 5.27 1.50 5.24 1.51 5.16 1.52
6.0 5.86 1.50 5.78 1.52 5.70 1.53 5.66 1.54 5.62 1.54 5.54 1.56
8.0 6.11 1.53 6.04 1.54 5.96 1.56 5.92 1.56 5.88 1.57 5.80 1.58
10.0 6.37 1.55 6.29 1.57 6.21 1.58 6.18 1.59 6.14 1.59 6.06 1.61
12.0 6.63 1.58 6.55 1.59 6.47 1.61 6.43 1.61 6.39 1.62 6.31 1.63
15.0 7.02 1.62 6.94 1.63 6.86 1.64 6.82 1.65 6.78 1.66 6.70 1.67
18.0 7.40 1.65 7.32 1.67 7.24 1.68 7.21 1.69 7.17 1.69 7.09 1.71
SYMBOLS
TC: Total capacity (kW)
PI: Power input (kW)
NOTE
1 Capacities are based on the following conditions.
Corresponding refrigerant piping length: 5m
Level difference: 0m
2 The bold line is indicated the standard condition.
3 The above is the value for connecting with the following indoor units.
2.0, 2.5, 3.5, 4.2, 5.0 kW Class: wall mounted series.
H
H
°°
