Daikin 2MXS40H2V1B [24/32] Capacity tables
![Daikin 2MXS40H2V1B [24/32] Capacity tables](/views2/1771726/page24/bg18.png)
• Outdoor Unit • Multi model application • MXS-H
• Split - Sky Air
®
• Outdoor Unit
22
4 Capacity tables
4 - 4 Heating Capacity Tables
2MXS50
★ Heating (50Hz 230V)
3D059197
Combination
(capacity)
Outdoor
air temp.
Indoor air temp.: °CDB
16°C 18°C 20°C 21°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CWB kW kW kW kW kW kW kW kW kW kW kW kW
2.5+4.2 -15.0 3.38 1.34 3.29 1.36 3.21 1.37 3.16 1.38 3.12 1.39 3.04 1.40
-11.0 3.93 1.40 3.84 1.41 3.76 1.43 3.72 1.44 3.67 1.44 3.59 1.46
-8.0 4.34 1.44 4.26 1.45 4.17 1.47 4.13 1.48 4.09 1.48 4.00 1.50
-6.0 4.62 1.47 4.53 1.48 4.45 1.50 4.40 1.50 4.36 1.51 4.28 1.53
-1.0 5.30 1.53 5.22 1.55 5.14 1.56 5.09 1.57 5.05 1.58 4.97 1.59
1.0 5.58 1.56 5.50 1.58 5.41 1.59 5.37 1.60 5.33 1.61 5.24 1.62
3.0 5.86 1.59 5.77 1.60 5.69 1.62 5.64 1.63 5.60 1.63 5.52 1.65
6.0 6.27 1.63 6.18 1.65 6.10 1.66 6.06 1.67 6.02 1.67 5.93 1.69
8.0 6.54 1.66 6.46 1.67 6.38 1.69 6.33 1.69 6.29 1.70 6.21 1.72
10.0 6.82 1.68 6.74 1.70 6.65 1.71 6.61 1.72 6.57 1.73 6.48 1.74
12.0 7.10 1.71 7.01 1.73 6.93 1.74 6.88 1.75 6.84 1.76 6.76 1.77
15.0 7.51 1.75 7.42 1.77 7.34 1.78 7.30 1.79 7.26 1.80 7.17 1.81
18.0 7.92 1.79 7.84 1.81 7.75 1.82 7.71 1.83 7.64 1.83 7.52 1.83
2.5+5.0 -15.0 3.49 1.33 3.40 1.35 3.31 1.36 3.27 1.37 3.23 1.38 3.14 1.39
-11.0 4.06 1.39 3.97 1.40 3.88 1.42 3.84 1.43 3.79 1.43 3.71 1.45
-8.0 4.48 1.43 4.40 1.44 4.31 1.46 4.26 1.47 4.22 1.47 4.13 1.49
-6.0 4.77 1.46 4.68 1.47 4.59 1.49 4.55 1.49 4.51 1.50 4.42 1.52
-1.0 5.48 1.53 5.39 1.54 5.30 1.55 5.26 1.56 5.22 1.57 5.13 1.58
1.0 5.76 1.55 5.68 1.57 5.59 1.58 5.55 1.59 5.50 1.60 5.41 1.61
3.0 6.05 1.58 5.96 1.59 5.87 1.61 5.83 1.62 5.79 1.62 5.70 1.64
6.0 6.47 1.62 6.39 1.64 6.30 1.65 6.26 1.66 6.21 1.66 6.13 1.68
8.0 6.76 1.65 6.67 1.66 6.58 1.68 6.54 168 6.50 1.69 6.41 1.71
10.0 7.04 1.67 6.96 1.69 6.87 1.70 6.83 1.71 6.78 1.72 6.70 1.73
12.0 7.33 1.70 7.24 1.72 7.15 1.73 7.11 1.74 7.07 1.75 6.98 1.76
15.0 7.75 1.74 7.67 1.76 7.58 1.77 7.54 1.78 7.49 1.79 7.41 1.80
18.0 8.18 1.78 8.09 1.80 8.01 1.81 7.96 1.82 7.92 1.83 7.80 1.83
3.5+3.5 -15.0 3.38 1.33 3.29 1.35 3.21 1.36 3.16 1.37 3.12 1.38 3.04 1.39
-11.0 3.93 1.39 3.84 1.40 3.76 1.42 3.72 1.43 3.67 1.43 3.59 1.45
-8.0 4.34 1.43 4.26 1.44 4.17 1.46 4.13 1.47 4.09 1.47 4.00 1.49
-6.0 4.62 1.46 4.53 1.47 4.45 1.49 4.40 1.49 4.36 1.50 4.28 1.52
-1.0 5.30 1.53 5.22 1.54 5.14 1.55 5.09 1.56 5.05 1.57 4.97 1.58
1.0 5.58 1.55 5.50 1.57 5.41 1.58 5.37 1.59 5.33 1.60 5.24 1.61
3.0 5.86 1.58 5.77 1.59 5.69 1.61 5.64 1.62 5.60 1.62 5.52 1.64
6.0 6.27 1.62 6.18 1.64 6.10 1.65 6.06 1.66 6.02 1.66 5.93 1.68
8.0 6.54 1.65 6.46 1.66 6.38 1.68 6.33 1.68 6..29 1.69 6.21 1.71
10.0 6.82 1.67 6.74 1.69 6.65 1.70 6.61 1.71 6.57 1.72 6.48 1.73
12.0 7.10 1.70 7.01 1.72 6.93 1.73 6.88 1.74 6.84 1.75 6.76 1.76
15.0 7.51 1.74 7.42 1.76 7.34 1.77 7.30 1.78 7.26 1.79 7.17 1.80
18.0 7.92 1.78 7.84 1.80 7.75 1.81 7.71 1.82 7.67 1.83 7.55 1.83
Combination
(Capacity)
Outdoor
air temp.
Indoor air temp.: °CDB
16°C 18°C 20°C 21 C 22 C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CWB kW kW kW kW kW kW kW kW kW kW kW kW
3.5+4.2 -15.0 3.43 1.34 3.35 1.36 3.26 1.37 3.22 1.38 3.17 1.39 3.09 1.40
-11.0 3.99 1.40 3.91 1.41 3.82 1.43 3.78 1.44 3.73 1.44 3.65 1.46
-8.0 4.41 1.44 4.33 1.45 4.24 1.47 4.20 1.48 4.15 1.48 4.07 1.50
-6.0 4.69 1.47 4.61 1.48 4.52 1.50 4.48 1.50 4.43 1.51 4.35 1.53
-1.0 5.39 1.53 5.31 1.55 5.22 1.56 5.18 1.57 5.13 1.58 5.05 1.59
1.0 5.67 1.56 5.59 1.58 5.50 1.59 5.46 1.60 5.41 1.61 5.33 1.62
3.0 5.95 1.59 5.87 1.60 5.78 1.62 5.74 1.63 5.69 1.63 5.61 1.65
6.0 6.37 1.63 6.29 1.65 6.20 1.66 6.16 1.67 6.11 1.67 6.03 1.69
8.0 6.65 1.66 6.57 1.67 6.48 1.69 6.44 1.69 6.39 1.70 6.31 1.72
10.0 6.93 1.68 6.85 1.70 6.76 1.71 6.72 1.72 6.67 1.73 6.59 1.74
12.0 7.21 1.71 7.13 1.73 7.04 1.74 7.00 1.75 6.95 1.76 6.87 1.77
15.0 7.63 1.75 7.55 1.77 7.46 1.78 7.42 1.79 7.37 1.80 7.29 1.81
18.0 8.05 1.79 7.97 1.81 7.88 1.82 7.84 1.83 7.77 1.83 7.64 1.83
3.5+5.0 -15.0 3.54 1.33 3.45 1.35 3.36 1.36 3.32 1.37 3.28 1.38 3.19 1.39
-11.0 4.12 1.39 4.03 1.40 3.94 1.42 3.90 1.43 3.85 1.43 3.77 1.45
-8.0 4.55 1.43 4.46 1.44 4.38 1.46 4.33 1.47 4.29 1.47 4.20 1.49
-6.0 4.84 1.46 4.75 1.47 4.67 1.49 4.62 1.49 4.58 1.49 4.49 1.52
-1.0 5.56 1.53 5.48 1.54 5.39 1.55 5.34 1.56 5.30 1.57 5.21 1.58
1.0 5.85 1.55 5.77 1.57 5.68 1.58 5.63 1.59 5.59 1.60 5.50 1.61
3.0 6.14 1.58 6.05 1.59 5.97 1.61 5.92 1.62 5.88 1.62 5.79 1.64
6.0 6.58 1.62 6.49 1.64 6.40 1.65 6.36 1.66 6.31 1.66 6.22 1.68
8.0 6.87 1.65 6.78 1.66 6.69 1.68 6.64 1.68 6.60 1.69 6.51 1.71
10.0 7.15 1.67 7.07 1.69 6.98 1.70 6.93 1.71 6.89 1.72 6.80 1.73
12.0 7.44 1.70 7.36 1.72 7.27 1.73 7.22 1.74 7.18 1.75 7.09 1.76
15.0 7.88 1.74 7.79 1.76 7.70 1.77 7.66 1.78 7.61 1.79 7.52 1.80
18.0 8.31 1.78 8.22 1.80 8.13 1.81 8.09 1.82 8.05 1.83 7.92 1.83
4.2+4.2 -15.0 3.49 1.36 3.40 1.37 3.31 1.39 3.27 1.40 3.23 1.40 3.14 1.42
-11.0 4.06 1.41 3.97 1.43 3.88 1.44 3.84 1.45 3.79 1.46 3.71 1.48
-8.0 4.48 1.46 4.40 1.47 4.31 1.49 4.26 1.49 4.22 1.50 4.13 1.52
-6.0 4.77 1.48 4.68 1.50 4.59 1.51 4.55 1.52 4.51 1.53 4.42 1.54
-1.0 5.48 1.55 5.39 1.57 5.30 1.58 5.26 1.59 5.22 1.60 5.13 1.61
1.0 5.76 1.58 5.68 1.60 5.59 1.61 5.55 1.62 5.50 1.63 5.41 1.64
3.0 6.05 1.61 5.96 1.62 5.87 1.64 5.83 1.65 5.79 1.65 5.70 1.67
6.0 6.47 1.65 6.39 1.66 6.30 1.68 6.26 1.69 6.21 1.70 6.13 1.71
8.0 6.76 1.68 6.67 1.69 6.58 1.71 6.54 1.72 6.50 1.72 6.41 1.74
10.0 7.04 1.71 6.96 1.72 6.87 1.74 6.83 1.74 6.78 1.75 6.70 1.77
12.0 7.33 1.73 7.24 1.75 7.15 1.76 7.11 1.77 7.07 1.78 6.98 1.79
15.0 7.75 1.77 7.67 1.79 7.58 1.80 7.54 1.81 7.49 1.82 7.41 1.83
18.0 8.18 1.82 8.09 1.83 7.96 1.83 7.89 1.83 7.82 1.83 7.69 1.83
SYMBOLS
TC: Total capacity (kW)
PI: Power input (kW)
NOTE
1 Capacities are based on the following conditions.
Corresponding refrigerant piping length: 5.0m
Level difference: 0m
2 The bold line is indicated the standard condition.
3 The above is the value for connecting with the following indoor units.
2.0, 2.5, 3.5, 4.2, 5.0 kW Class; wall mounted series.
