• Outdoor Unit • Multi model application • MXS-H
• Split - Sky Air
®
• Outdoor Unit
12
4 Capacity tables
4 - 3 Cooling Capacity Tables
2MXS40H2V1B
Cooling (50Hz 230V)
Combination
(Capacity)
Outdoor air
temp.
°CDB
Indoor air temperature: °CWB
14°C 16°C 18°C 19°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5 + 2.5
10.0 4.81 0.89 5.00 0.91 5.20 0.93 5.30 0.94 5.60 0.97 5.80 0.99
12.0 4.73 0.91 4.92 0.93 5.12 0.95 5.22 0.96 5.52 0.99 5.72 1.01
15.0 4.61 0.94 4.80 0.96 5.00 0.98 5.10 0.99 5.40 1.02 5.60 1.04
18.0 4.49 0.97 4.68 0.99 4.88 1.01 4.98 1.02 5.28 1.05 5.48 1.07
20.0 4.41 1.00 4.60 1.02 4.80 1.04 4.90 1.05 5.20 1.08 5.40 1.09
22.0 4.33 1.02 4.52 1.04 4.72 1.06 4.82 1.07 5.12 1.10 5.32 1.12
25.0 4.21 1.06 4.40 1.08 4.60 1.10 4.70 1.11 5.00 1.14 5.20 1.15
28.0 4.09 1.09 4.28 1.11 4.48 1.13 4.58 1.14 4.88 1.17 5.08 1.19
32.0 3.92 1.15 4.12 1.17 4.32 1.19
4.42 1.20
4.72 1.23 4.92 1.25
35.0 3.80 1.19 4.00 1.21 4.20 1.23 4.30 1.24 4.60 1.27 4.80 1.29
40.0 3.60 1.27 3.80 1.29 4.00 1.31
4.10 1.32
4.40 1.35 4.60 1.37
43.0 3.48 1.32 3.68 1.34 3.88 1.36 3.98 1.37 4.28 1.40 4.47 1.42
46.0 3.26 1.30 3.41 1.30 3.57 1.30 3.64 1.30 3.86 1.30 4.00 1.30
2.5 + 3.5
10.0 5.03 0.97 5.24 0.99 5.44 1.01 5.55 1.03 5.86 1.06 6.07 1.08
12.0 4.95 0.99 5.15 1.01 5.36 1.04 5.46 1.05 5.77 1.08 5.98 1.10
15.0 4.82 1.02 5.03 1.05 5.23 1.07 5.34 1.08 5.65 1.11 5.86 1.13
18.0 4.69 1.06 4.90 1.08 5.11 1.10 5.21 1.11 5.52 1.15 5.73 1.17
20.0 4.61 1.08 4.82 1.11 5.02 1.13 5.13 1.14 5.44 1.17 5.65 1.19
22.0 4.53 1.11 4.73 1.13 4.94 1.15 5.04 1.16 5.36 1.20 5.56 1.22
25.0 4.40 1.15 4.61 1.17 4.82 1.19 4.92 1.20 5.23 1.24 5.44 1.26
28.0 4.28 1.19 4.48 1.21 4.69 1.23 4.79 1.25 5.10 1.28 5.31 1.30
32.0 4.11 1.25 4.31 1.27 4.52 1.29
4.63 1.30
4.94 1.34 5.14 1.36
35.0 3.98 1.30 4.19 1.32 4.40 1.34 4.50 1.35 4.81 1.38 5.02 1.41
40.0 3.77 1.38 3.98 1.40 4.19 1.42
4.29 1.43
4.60 1.47 4.81 1.49
43.0 3.65 1.43 3.85 1.45 4.06 1.48 4.16 1.49 4.44 1.50 4.60 1.50
46.0 3.23 1.30 3.38 1.30 3.53 1.30 3.60 1.30 3.81 1.30 3.95 1.30
3D063456A
NOTES SYMBOLS
1 Capacities are based on the following conditions.
Corresponding refrigerant piping length: 5.0m
Level difference: 0m
2 The bold line is indicated the standard condition.
3 The above is the value for connecting with the following indoor units.
2.0, 2.5, 3.5 kW class; wall mounted ATX-G, ATX-J, FTX-J (GSI-S)series.
TC: Total capacity (kW)
PI: Power input (kW)
