Daikin 2MXS40H2V1B [6/32] Specifications
![Daikin 2MXS40H2V1B [6/32] Specifications](/views2/1771726/page6/bg6.png)
• Outdoor Unit • Multi model application • MXS-H
• Split - Sky Air
®
• Outdoor Unit
4
2 Specifications
Piping connections Liquid Quantity 2
OD mm 6.35
Gas Quantity 2 1
OD mm 9.5
Drain Quantity 1
OD mm 18
Gas 2 Quantity - 1
OD mm - 12.7
Additional refrigerant charge kg/m 0.02 (for piping length exceeding 20m)
Piping length OU - IU Min. m 3
OU - IU Max. m 20
Level difference IU - OU Max. m 15
IU - IU Max. m 7.5
Heat insulation Both liquid and gas pipes
Total piping length System Actua
l
m30
2-2 Electrical Specifications
2MXS40H2V1B 2MXS50H2V1B
Power supply Phase 1~
Frequency Hz 50
Voltage V 220-240
Current Starting current Cooling A 4.6 6.3
Heating A 4.6 6.3
Wiring connections For power supply Remark 3 for power supply, 4 for interunit wiring (including earth wiring)
2-1 Technical Specifications
2MXS40H2V1B 2MXS50H2V1B
