SiBE18-821 Test Operation
Test Operation 125
Note: If you want to repeat the automatic refrigerant charging operation from step 4.1, fully open the
liquid and gas side stop valves and press the BS1 MODE button once.
4.3 When the led indication becomes as shown in the table below in about 15 to 30 minutes
after start of operation, open valve A at once to start charging of the refrigerant.
Immediately after starting charging of the refrigerant by opening valve A, press BS4 TEST
once. When BS4 TEST is not pressed within 10 minutes after the led indication is shown,
charging is stopped.
4.4 The led indication becomes as shown in the table below during automatic refrigerant
charging.
During automatic refrigerant charging, the remote controller indicates TEST (test operation)
and (external control).
Note: If the led display below appears, the refrigerant tank is empty. Replace the refrigerant tank,
open valve A and re-charge.
The led indication becomes as shown in the table below when automatic refrigerant charging is
about to end. Prepare to close the valve on the refrigerant tank.
Note: It is possible that the code PE is not shown on the remote controller but this does not indicate a
malfunction. The led indication can immediately shift to the situation as shown in "Case 1:
Charging complete" on page 126.
4.5 When the led indication becomes as shown in the table below, quickly close valve A and
follow instructions as described below.
H1P H2P H3P H4P H5P H6P H7P Code on remote controller
jjjhihi
PA
H1P H2P H3P H4P H5P H6P H7P
ij ∗∗∗∗∗
H1P H2P H3P H4P H5P H6P H7P Code on remote controller
ijjhhih
PA
H1P H2P H3P H4P H5P H6P H7P Code on remote controller
jjjiiii
PE
