Troubleshooting for Outdoor Unit SiBE18-821
332 Troubleshooting
Troubleshooting
Check No.03
Refer to P.348
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Is the power
supply voltage
200~240V ±10%?
Is the P-N
resistance not less
than several hundred
of ohms?
Check No.03
Is the resistance above
standard value?
Is the
measured voltage 220
VDC or more?
Correct power supply
Field factors
Replace the inverter PC
board (A1P).
(Q0576)
YES
YES
YES
NO
NO
Replace the fan motor
NO
Monitor the voltage
(Instantaneous voltage
drop)
YES
NO
When the compressor is
running, measure the voltage
between + and - of electrolytic
capacitor (C+, C-).
