SiBE18-821 Test Operation
Test Operation 127
Error codes on the remote controller
After correcting the problem, press BS1 MODE button once and perform automatic refrigerant
charging again starting from step 4.1.
Installation error Malfunction code Remedial action
The stop valve of an outdoor unit is left
closed.
E3
Open the stop valve on both the gas and liquid
side.
The stop valve of an outdoor unit is left
closed.
E4
F3
Open the stop valve on both the gas and liquid
side.
Insufficient refrigerant Check if the additional refrigerant charge has
been finished correctly. Recalculate the
required amount of refrigerant from the piping
length and add an adequate amount of
refrigerant.
Refrigerant overcharge
E3
F6
Recalculate the required amount of refrigerant
from the piping length and correct the
refrigerant charge level by recovering any
excessive refrigerant with a refrigerant
recovery machine.
Insufficient supply voltage
U2
Check if the supply voltage is supplied
properly.
The check operation is not performed.
U3
Perform the check operation.
No power is supplied to the outdoor unit.
U4
Check if the power wiring for the outdoor unit is
connected correctly.
Improper type of indoor units are
connected.
UA
Check the type of indoor units that are currently
connected. If they are not proper, replace them
with proper ones.
The stop valve of an outdoor unit is left
closed.
UF
Open the stop valve on both the gas and liquid
side.
The piping and wiring of the specified
indoor unit are not connected correctly to
the outdoor unit.
Confirm that the piping and wiring of the
specified indoor unit are connected correctly to
the outdoor unit.
Incorrect interconnections between
units.
UH
Connect correctly the interconnections
between units to the F1 and F2 (TO IN/D UNIT)
terminals on the PC board in the outdoor unit.
Power supply cables are connected in
the reverse phase instead of the normal
phase.
U1
Connect the power supply cables in normal
phase. Change any two of the three power
supply cables (L1, L2, L3) to correct phase.
