Test Operation SiBE18-821
126 Test Operation
Caution
♦
When adding refrigerant is done or when pausing, close the valve on the refrigerant tank
immediately.
More refrigerant might be charged by any remaining pressure after the machine is stopped.
♦
The outdoor fan may keep rotating a little bit more, but this does not indicate a malfunction.
Case 1: Charging complete
Charging of the refrigerant is complete. Press BS1 MODE button once and go to step 5.
Case 2: Recharging operation
Press BS1 MODE button once and perform automatic refrigerant charging again starting from
Step 4.1.
Case 3: Charging interrupted
Something is preventing normal operation:
♦
Is the gas side stop valve completely open?
♦
Are the valve on the refrigerant tank and valve A open?
Check if the BS4 TEST button was pressed within 10 minutes after the valves were opened.
♦
Is the indoor unit air intake vent or outlet vent blocked?
After correcting the problem, press BS1 MODE button once and perform automatic refrigerant
charging again starting from step 4.1.
Case 4: Failure
(*) An error in the system interrupted the operation of the unit. Check the error by using the
error code displayed on the remote controller. For an explanation of the error codes, see the
chart below.
H1P H2P H3P H4P H5P H6P H7P Code on remote controller
ijjiiii
P9
H1P H2P H3P H4P H5P H6P H7P Code on remote controller
ijjhiii
P8
H1P H2P H3P H4P H5P H6P H7P Code on remote controller
ijjhhhi
P2
H1P H2P H3P H4P H5P H6P H7P
Error code on remote
controller
hiihhhh
See footnote
(*)
