Specifications SiBE18-821
12 Specifications
1.3 Indoor Units
Wall Mounted Type
50Hz 230V
Model
FTXG25EV1BW FTXG25EV1BS
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 2.5kW Class
Front Panel Color Mat Crystal White Mat Crystal Silver
Airflow Rates
m³/min
(cfm)
H 7.7 (271) 9.0 (317) 7.7 (271) 9.0 (317)
M 6.1 (215) 7.9 (278) 6.1 (215) 7.9 (278)
L 4.7 (165) 6.7 (236) 4.7 (165) 6.7 (236)
SL 3.8 (134) 5.4 (190) 3.8 (134) 5.4 (190)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13
Power Consumption (Rated) W 30-30-30 30-30-30 30-30-30 30-30-30
Power Factor % 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 38/32/25/22 38/33/28/25
Sound Power H dBA 56 56 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051101 3D051102
Model
FTXG35EV1BW FTXG35EV1BS
Cooling Heating Cooling Heating
Rated Capacity 3.5kW Class 5.0kW Class
Front Panel Color Mat Crystal White Mat Crystal Silver
Airflow Rates
m³/min
(cfm)
H 8.1 (285) 9.6 (338) 8.1 (285) 9.6 (338)
M 6.5 (229) 8.2 (289) 6.5 (229) 8.2 (289)
L 4.9 (173) 6.7 (236) 4.9 (173) 6.7 (236)
SL 4.1 (144) 5.9 (208) 4.1 (144) 5.9 (208)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13
Power Consumption (Rated) W 30-30-30 30-30-30 30-30-30 30-30-30
Power Factor % 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 39/33/26/23 39/34/29/26 39/33/26/23 39/34/29/26
Sound Power H dBA 57 57 57 57
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051103 3D051104
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
