Key names
Short
designation
Explanation Short
designation
Explanation
RoCon BM1
J9 Plug connection FLS (t
R1
/ V1) SG
Switching contact for Smart Grid (intelligent mains
connection)
J10 Plug connection internal cabling to X19A (A1P) TRA1 Transformer
J11 Plug connection internal cabling to X18A (A1P) t
AU
External temperature sensor (RoCon OT1)
J12 Plug connection 3UV DHW t
DHW1
Storage tank temperature sensor 1 (RoCon BM1)
J13 Plug connection System-Bus (e.g. room station) t
DHW2
2 (A1P) storage tank temperature sensor
J14 Plug connection circulation pump P
Z
t
R1
Return flow temperature sensor 1 (FLS - RoCon
BM1)
J15 Plug connection internal cabling (strapping plug) t
R2
Return flow temperature sensor 2 (A1P)
J16
Plug connection room thermostat (EKRTR /
EKRTW)
t
V1
Flow temperature sensor 1 (A1P)
EHS157068 Mixer module t
V, BH
Flow temperature sensor Backup-Heater (A1P)
EHS157034 Room station V1 Flow sensor (FLS - RoCon BM1)
Cooling out-
put
Output status for "Cooling" operating mode XAG1 Plug connection exterior heat pump unit
RT Room thermostat (EKRTW) XBUH1 Plug connection Backup-Heater (EKBUxx)
RT-E Receiver for radio room thermostat (EKRTR) X2M6 Connecting cable clamp HPc-VK-1
RTX-EHS Switch board (Backup-Heater) X2M7 Connecting cable clamp HPc-VK-1
RTX-EHS
K1 Relay 1 for Backup-Heater X11M Terminal block in FWXV(15/20)AVEB
K2 Relay 2 for Backup-Heater
K3 Relay 3 for Backup-Heater
X1
Terminal block for mains connection to Backup-
Heater
X3
Plug connection internal cabling to J17
(RoCon BM1)
Tab. 4-4 Key names for connections and circuit diagrams - Part 2
4 x Set-up and installation
Daikin Altherma EHS(X/H)
Daikin Altherma integrated solar unit
008.1441399_02 – 01/2021 – EN
Installation and operating instructions
39
