Daikin EHSXB08P50BA [70/84] X hydraulic system connection
![Daikin EHSXB08P50BA [70/84] X hydraulic system connection](/views2/1786037/page70/bg46.png)
Short name. Meaning
1 Cold water distribution network
2 Hot water distribution network
3 Heating flow
4 Heating return flow
5 Mixer circuit (optional)
6 Circulation (optional)
7 Check valve, return valve
7a Non return valves
8 Solar circuit
9 Gas pipe (coolant)
10 Fluid pipe (coolant)
3UVB1
3-way diverter valve (internal heat generation cir-
cuit)
3UV DHW 3 way diverter valve (hot water/heating)
EKBUxx Backup-Heater
BV Bypass valve
C Coolant compressor
CW Cold water
DHW Domestic hot water
E Expansion valve
FLG FlowGuard regulating valve with flow indicator
FLS
FlowSensor - solar flow and feed flow tempera-
ture measurement
H
1,
H
2
… H
m
Heating circuits
MAG Diaphragm expansion vessel
MIX 3-way-mixer with drive motor
MK1 Mixer group with high-efficiency pump
MK2
Mixer group with high-efficiency pump
(PWM controlled)
P
Mi
Mixing circuit pump
P
S
Solar operating pump
P
W1
Primary circuit pump W
EX
P
W2
Secondary circuit pump W
EX
P
Z
Circulation pump
PWT Panel heat exchanger (condenser)
RoCon HP Control unit for Daikin Altherma EHS(X/H)
EHS157068 Mixer circuit control
EKSRPS4A Solar regulating and pump unit
RPWT1 Plate heat exchanger
ERLQ Exterior heat pump unit
SAK2 Storage tank connection (wood boiler)
SAS1 Sludge and magnetic separator
SK Solar panel field
SV Safety over-pressure valve
t
AU
Outside temperature sensor
RoCon OT1 (see chapter 4.5.9)
t
DHW
Storage tank temperature sensor (heat genera-
tor)
t
Mi
Mixer circuit flow temperature sensor
T
K
Solar collector temperature sensor
T
R
Solar return flow temperature sensor
T
S
Solar storage cylinder temp. sensor
T
V
Solar flow temperature sensor
TMV
Thermostatic 3-way valve for return temperature
increase
V Fan (vaporiser)
VS Protection against scaldingVTA32
W
EX
External heat generator
Tab. 9-1 Short names in hydraulic drawings
Installation and operating instructions
70
Daikin Altherma EHS(X/H)
Daikin Altherma integrated solar unit
008.1441399_02 – 01/2021 – EN
9 x Hydraulic system connection
Short name. Meaning
