10 x Technical data
Daikin Altherma EHS(X/H)
Daikin Altherma integrated solar unit
008.1441399_02 – 01/2021 – EN
Installation and operating instructions
75
Refrigerant circuit
Number of circuits — 1
Pipe connections
Number — 2
Liquid line
Type — Flanged connection
External Ø inches 1/4" AG 3/8" AG 1/4" AG 3/8" AG
Gas lines
Type — Flanged connection
External Ø inches
5/8" AG
Operating data
Operating range
Flow temperature
for room heat-
ing/cooling func-
tion
Heating
(min/max)
°C
15 to 55
Cooling
(min/max)
°C 5 to 22
Hot water genera-
tion (with EKBUxx)
Heating
(min/max)
°C 25 to 80
Noise level
Audibility dBA 39
Noise pressure
2)
dBA 28 32 28 32
Electrical data:
Voltage supply
Phases — 1
Voltage V 230
Voltage range V Voltage ±10%
Frequency Hz 50
Mains connection
3)
Daikin Altherma EHS(X/H)
Circuit board RoCon BM1
— 3G
Communication in the heat pump
exterior unit -< > Daikin Altherma
EHS(X/H), Switch board A1P
— 3G
External unit for heat pump —
3G
3G (ERLQ…V3) /
5G (ERLQ…W1)
3G 3G (ERLQ…V3) /
5G (ERLQ…W1)
Optional auxiliary
heating
Backup-Heater
(EKBUxx)
—
3G (1-phase) / 5G (3-phase)
Performance data
Type exterior heat pump unit
ERLQ006CAV3/
ERLQ008CAV3
ERLQ011CA
(V3/W1)*/
ERLQ014CA
(V3/W1)*/
ERLQ016CA
(V3/W1)*
ERLQ006CAV3/
ERLQ008CAV3
ERLQ011CA
(V3/W1)*/
ERLQ014CA
(V3/W1)*/
ERLQ016CA
(V3/W1)*
Nominal heat output A-7/W35 kW
5.29 / 5.53 6 / 8.3 / 8 5.29 / 5.53 6 / 8.3 / 8
Nominal heat output A2/W35 kW
4.6 / 5.51 7.7 / 9.6 / 10.1 4.6 / 5.51 7.7 / 9.6 / 10.1
Nominal heat output A7/W35 kW
6.06 / 7.78 11.8 / 14.8 / 15.3 6.06 / 7.78 11.8 / 14.8 / 15.3
Nominal heat output A10/W35 kW
6.6 / 8.4 11.5 / 14.5 / 16.1 6.6 / 8.4 11.5 / 14.5 / 16.1
Nominal cooling output A35/W18 kW
5.22 / 5.22 10.6 / 10.6 / 10.6 5.22 / 5.22 10.6 / 10.6 / 10.6
Nominal cooling output A35/W7 kW
4.46 / 4.64 11.7 / 12.6 / 13.1 4.46 / 4.64 11.7 / 12.6 / 13.1
Nominal COP A-7/W35
2.73 / 2.78 2.45 / 2.58 / 2.44 2.73 / 2.78 2.45 / 2.58 / 2.44
Nominal COP A2/W35
3.64 / 3.54 3.29 / 3.22 / 3.15 3.64 / 3.54 3.29 / 3.22 / 3.15
Nominal COP A7/W35
4.65 / 4.6 4.38 / 4.27 / 4.1 4.65 / 4.6 4.38 / 4.27 / 4.1
Nominal COP A10/W35
4.95 / 4.9 4.6 / 4.41 / 4.31 4.95 / 4.9 4.6 / 4.41 / 4.31
Nominal EER A35/W18
3.65 / 3.65 3.9 / 3.9 / 3.9 3.65 / 3.65 3.9 / 3.9 / 3.9
Nominal EER A35/W7
2.51 / 2.51 2.72 / 2.47 / 2.29 2.51 / 2.51 2.72 / 2.47 / 2.29
Max. heating output A-7/W35 kW
5.3 / 6.4 8.8 / 11.7 / 12.3 5.3 / 6.4 8.8 / 11.7 / 12.3
Max. heat output A2/W35 kW
6.4 / 7.7 9.1 / 10.9 / 11.4 6.4 / 7.7 9.1 / 10.9 / 11.4
Type Daikin Altherma EHS(X/H)
08P50B 16P50B B08P50B B16P50B
