Daikin EHSXB08P50BA [61/84] X errors malfunctions and messages
![Daikin EHSXB08P50BA [61/84] X errors malfunctions and messages](/views2/1786037/page61/bg3d.png)
8 x Errors, malfunctions and messages
Daikin Altherma EHS(X/H)
Daikin Altherma integrated solar unit
008.1441399_02 – 01/2021 – EN
Installation and operating instructions
61
E9004 7H Fault volume flow Flow sensor FLS
Water flow is too low or there is none at all. Minimum water flow
required:
– Operating mode "Heating": 600 l/h
– Operating mode "Cooling": 840 l/h
– Automatic defrosting function (
) active: 1020 l/h
Check the following items:
● All stop valves of the water circuit must be completely open.
● Optional water filters must not be contaminated.
● Heating system must run within its operating range.
● Heating system and device-internal circulation pump must be
completely bled.
● On the controller (rotary switch setting "Info"
) check
whether there is adequate water pressure (>0.5 bar).
● Check the function of the 3-way switching valve 3UVB1
(compare actual setting of 3UVB1 with BPV position
[Overview] displayed in the parameter).
● If this fault occurs during defrost operation in the operating
mode room heating or hot water supply? With optional
Backup-Heater: check its power supply and fuses.
● Check the fuses in the control housing of the Daikin Altherma
EHS(X/H) (pump fuse (FU1) on circuit board A1P and printed
circuit board fuse (F1) on the RoCon BM1 circuit board).
● Check flow sensor FLS for contamination and function, if
necessary clean, replace.
E9005 8F
Flow temperature
t
V, BH
>75 °C
Flow temperature
sensor t
V, BH
Flow temperature of the Backup-Heater (t
V, BH
) is too high.
– Flow temperature sensor sending incorrect values. Tempera-
ture sensor or connecting cable defective.
● Check, replace.
– Contact problem A1P-bridge on X3A.
E9006 8H
Flow temperature
t
V, BH
>65 °C
Flow temperature
sensor t
V, BH
E9007 A1 IU main board def Circuit board A1P
Communication between the heat pump exterior equipment and
heat pump interior equipment malfunctioning.
– Electromagnetic influences.
● Perform reset.
– Circuit board A1P defective.
● Replace circuit board A1P.
E9008 A5
Coolant tempera-
ture outside of the
valid range
Temperature sensor
(liquid-side coolant) t
L2
No heat absorption at the plate heat exchanger.
● Check flow.
● If the flow is OK, then replace the coolant temperature sensor.
E9009 AA
STB fault
Optional: STB Backup-
Heater (EKBUxx)
Thermal protection switch (STB) on Backup-Heater (EKBUxx)
was triggered.
● Replace Backup-Heater (EKBUxx).
E9010 AC Bridge on board A1P
Bridge of connection socket "X21A" missing on board A1P.
● Plug in strapping plug.
E9011 C0 Fault flow sensor Flow sensor FLS
Flow sensor FLS defective.
● Replace flow sensor FLS.
E9012 C4 Fault feed flow
Flow temperature sensor
t
V1
or t
V, BH
Measurement outside the permitted value range. Sensor or con-
nection cable defective.
● Check, replace.
E9013 E1 OU main board def
Main board of the heat
pump exterior unit
– Main board in the heat pump exterior unit defective.
– Ventilator motor defective.
● Check, replace.
Code Malfunction /
Error messages
Component/Designation Causes and possible error correction
Display Internal
