![Einhell RT-SB 250 U [20/68] Important notes](/views2/1079469/page20/bg14.png)
4. Important notes
Safety information
IMPORTANT! Whenever you use electric tools it is
imperative to take basic safety precautions in order
to reduce the risk of fire, electric shock and personal
injury.
The corresponding safety information can be found
in the enclosed booklet.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
5. Technical data
Voltage: 220-240V ~ 50 Hz
Power: 420 W
Ideal speed no: 1400 min
-1
Blade length: 1790 mm
Max. blade width: 9,5 mm
Blade speed: 660/960 m/min
Max. cutting height: 120 mm / 90°
70 mm / 45°
Throat: 245 mm
Table size: 290 x 290 mm
Tilting range of table: 0° to 45°
Workpiece size: 350 x 350 mm
Weight: 32,8 kg
Noise emission values
Sound and vibration values were measured in
accordance with EN 61029.
L
pA
sound pressure level 77,4 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 90,4 dB(A)
K
WA
uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever
necessary.
Switch the appliance off when it is not in use.
6. Before putting the machine into
operation
앬 Make sure the machine stands securely, i.e. bolt
it to a workbench or solid base. There are two
holes for this purpose in the machine foot.
앬 The saw table must be mounted correctly.
앬 All covers and safety devices have to be properly
fitted before the machine is switched on.
앬 It must be possible for the blade to run freely.
앬 When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
앬 Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machineʼs moving parts run smoothly.
앬 Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
7. Assembly
CAUTION!
Pull out the power plug before carrying out any
maintenance, resetting or assembly work on the
bandsaw!
7.1 Assembling the base frame and bolting the
saw to the base frame (Fig. 7-23)
앬 Insert the feet (A) from the bottom into the
intermediate struts (C) as shown in Figure 7.
Ensure that the rubber stoppers on the feet (A)
are aligned so that the support surfaces are level.
앬 Screw the feet (A) to the intermediate struts (C)
using the screws (N), washers (H) and nuts (G)
as shown in Figures 8 - 9.
앬 Guide the side parts (B) from the top over the
intermediate struts (C) (Figure 10).
앬 At each connection point screw the side parts (B)
to the intermediate struts (C) using three screws
(L), washers (K) and nuts (I) (Figures 11-12).
앬 Insert the two bottom cross struts (E) into the
20
GB
Anleitung_RT_SB_250_U_SPK7:_ 10.02.2012 9:57 Uhr Seite 20
