Daikin RZQ140B7W1B [108/326] Preheating operation control
![Daikin RZQ125B8V3B [108/326] Preheating operation control](/views2/1794903/page108/bg6c.png)
General Functionality ESIE05-03
2–24 Part 2 – Functional Description
3
1
2
4
5
1.17 Preheating Operation Control
Applicable units RZQ71
Outline After the compressor has been turned off, the preheating operation will be activated in order to avoid
refrigerant from dissolving in the compressor oil.
Trigger conditions
Starting conditions &
P or
P T2 (Discharge pipe temperature) < 40°C
P Ta (Outside temperature) < 40°C
P Power supply ON to First operation
P 60 minutes or more elapsed after compressor stop
Ending conditions or
P T2 (Discharge pipe temperature) > 43°C
P Ta (Outside temperature) > 43°C
P Thermostat ON confirmation
ESIE05-03.book Page 24 Wednesday, April 6, 2005 4:09 PM
