ESIE05-03 Field settings
Part 4 – Commissioning and Test Run 4–21
3
4
5
1
2.9 Overview of the Field Settings on the Outdoor Units
Remote controller
settings
The table below contains the remote controller settings.
Jumpers The table below contains the jumper field settings.
Location on PCB A1P: see drawing on next page.
Mode N° First
code
Description Second n° Details
01 02 03 04 05
16 or 26 0 Night time low
noise operation
Disabled
(Factory
setting)
Automatic
low noise
activation
Capacity
preceding
setting
(when
using
KRP58
option)
Automatic
low noise +
capacity
preceding
—4–24
1 Automatic low
noise start and
stop time
— — 22h00 ~
06h00
22h00 ~
08h00
(Factory)
20h00 ~
08h00
4–24
2 EDP room set-
ting
Disabled
(Factory
setting)
—EDP room
setting
EDP room
setting +
no freeze
up
—4–28
3 Defrost starting
setting
Standard
(Factory
setting)
Defrost
slow start-
ing setting
Defrost
quick start-
ing setting
——2–19
Jumper Label on PCB Function Details
JX5 JX5 Set as cooling only —
ESIE05-03.book Page 21 Wednesday, April 6, 2005 4:09 PM
