Test Run and Operation Data ESIE05-03
4–36 Part 4 – Commissioning and Test Run
3
1
4
5
3.1 General Operation Data
Guide Lines for
Optimal Operation
Condition
The operation value guide lines when operating under standard conditions (at Rated frequency) by
pushing the test run button on the remote controller are as given in the table below.
Indoor Unit Fan: “H” Operation Compressor: Rated Frequency
High
Pressure
(Mpa)
Low
Pressure
(Mpa)
Discharge
Pipe
Temperature
(°C)
Suction
Temperature
(°C)
Indoor Unit
Side:
Differential
Between
Suction Tem-
perature and
Discharge
Temperature
(°C)
Outdoor Unit
Side:
Differential
Between
Suction Tem-
perature and
Discharge
Temperature
(°C)
Cooling 26 bar ~
34 bar
6 bar ~
10 bar
60~100 –2~10 8~18 7~12
Heating 25 bar ~
32.6 bar
5.3 bar ~
7.5 bar
60~100 –6~2 14~30 2~6
