Haier AC36NACAAA [15/87] Net dimensions of indoor and outdoor unit
![Haier AC36NACAAA [15/87] Net dimensions of indoor and outdoor unit](/views2/1807752/page15/bgf.png)
Note (1) Fix the parts with screws
(2)Don't intake the strong wind directly
to the outlet air-flow hole.
(3)A one meter distance should be
kept from the unit top
(4)Don't block the surroudings of the unit with sundries.
Installation Servicing Space(at Least)
Unit:mm
Installation
I
300
100
0
0
150
0
500
100
0
II III
Dimension
L1
Leave space Leave space
Leave space
L2
L3
L4
185 185
55
70
70
Screw Hole
(M10)
580
Power Wiring Terminal
Power Wiring
Distribution Hole
L1
L2
L3
L4
Back Air-flow Hole
Back Air-
flow Hole
Outlet Air-flow Hole
Repairing Space
70
1024
1818
340
380
840
25
Model: HCFU-24H03 HCFU-28HC03 Outdoor unit
NET DIMENSIONS OF INDOOR AND OUTDOOR UNIT
