Haier AC36NACAAA [53/87] Diagnostic information trouble shooting
![Haier AC282ACABA [53/87] Diagnostic information trouble shooting](/views2/1807752/page53/bg35.png)
Trouble Checkup result Possible reasons Corresponding solution
During heating program,
the compressor work while
outdoor blowing fan does
not
Too high temperature of indoor coil pipe
causes overheat protection
It will automatically restore when
the temperature of indoor coil
pipe falls to 57
No output at collector of Q2 on
indoor board
Damaged Q2 Replace with a good Q2
No output of relay JK8 on indoor
board
Damaged relay JK8 on indoor board Replace with a good JK8
During heating program,
the compressor work while
outdoor blowing fan does
not
Available output of relays on
indoor board
Socket CN6 is not plugged well with
connection cable
Plug the connection cable well
Current transformer outputs
normally
Damaged rectification diode D6-D7 etc.
Return to the controller
manufacturer for repair
Transformer CT1outputs
ormally
abn
Damaged transformer CT1 Replace with a good one
Inaccurate protection current Adjust the adjustable potentiometer
Abnormal overcurrent
detection
Damaged major chip
Return to the controller
manufacturer for repair
With timing indicator and
compressor indicator
extinguishing, the
operation indicator flashes
every second
Damaged indoor temperature sensor Replace with a good one
With timing indicator and
compressor indicator
lighting, the operation
indicator flashes every
second
Damaged temperature sensor for indoor
coil pipe
Replace with a good one
No output at 13 pin of 2803 on
indoor board
Damaged 2803 Replace with a good 2803
N
b
o output of relay JK6 on indoor
oard
Damaged relay JK4 on indoor board Replace with a good JK4
Available output of relay JK6 on
indoor board
Socket CN5 is not plugged well with
connection cable
Plug the connection cable well
Water pump indicator
flashes every second
(trouble for water
discharging)
Faulty connection cable to transmit float
feedback signal
Replace with a good one
DIAGNOSTIC INFORMATION (TROUBLE SHOOTING)
