Haier AC36NACAAA [70/87] Exploded views parts lists
![Haier AC36NACAAA [70/87] Exploded views parts lists](/views2/1807752/page70/bg46.png)
HCFU-24H03 HCFU-28HC03 Part list of outdoor unit
No Name of parts Part specialized code QTY. Remark
1 Front grille 001A1236028 1
2 handle 001A1436160 2
3 Front panel 001A1101078 1
4 service panel assy 001A0100524 1
5 Axial fan 001A5402022 1
6 Fan motor 001A3000082 1
7 Bracket for fan motor 001A0100266 1
8 Condenser assy. 001A0400119 1
9 Electric box 001A1301453 1
10 Capacitor for fan motor 001A3600018 1
11 connection block 001A4000011 1
12 Capacitor for compressor 001A3600030 1
13 Capacitor clamp 0010100001 1
14 AC contactor 001A3900161 1
15 Terminal block 001A4000151 1
16 electrical source connection block 001A4000110 1
17 cable clamp 001A5731054 1
18 outlet Air pipe assy. 001A0500368 1
19 inlet Air pipe assy. 001A0500364 1
20 filter 001A2411023 1
21 3-way stop valve 001A2500154 1
22 2-way stop valve 001A2500153 1
23 muffle 001A2111911 1
24 Compressor(ZR34K3E-PFJ-522) 001A2000201 1
25 Partition plate 001A0100350 1
26 Top cover assy. 001A0100264 1
27 Back grille 001A0100109 1
28 Junction box 001A0100394 1
29 Slide plate(right) 001A0100390 1
30 Valve pedestal 001A1301506 1
31 branch triby 001A1301117 2
32 Bottom cover assy. 001A0100351 1
33 Wiring assy. 0010450408 1
34 Fan Speed Controller 0010450176 1
EXPLODED VIEWS & PARTS LISTS
