Haier AC36NACAAA [64/87] Exploded views parts lists
![Haier AC36NACAAA [64/87] Exploded views parts lists](/views2/1807752/page64/bg40.png)
HCFU-14H03 HCFU-18HC03 Part list of indoor unit
No. Name of part specialized number QTY. Remark
1 air filter 001A2400087 2
2 inlet grill assy 001A0100330 1
3 fixing plate 001A1301398 2
4 strengthen tendon 001A1301395 1
5 pinch plate 001A1301399 2
6 wiring assembly 001A4400509 1
7 Fan motor capacitor 2uf 001A3600009B 1
8 transformer 001A3800141 1
9 indoor PCB 0010400020 1
10 termonal block 001A4000084 1
11 Power line clip 001A14311292 1
12 wiring block 001A1431326 1
13 environment temp. Sensor indoor 001A3900005 1
14 clamp plate of motor 001A1301382 1
15 connecting rod of motor 001A1301383 1
16 Fan motor bracket 001A1301381 1
17 small block 001A1443592 1
18 Indoor fan motor 001A3000109 1
19 centrifugal fan 001A2300042 2
20 drainage elbow 001A1436664 1
21 scroll case 1 001A1431608 2
22 scroll case 2 001A1431609 2
23 Pipe temp. sensor indoor 001A3900006 1
24 Air inlet tube assy. 001A2111677 1
25 liquid pipe 0010750130 1
26 back framework 001A1734862 2
27 handle 001A1436606 4
28 right wallboard 001A1101104 1
29 plate assy right 001A1101041 1
30 long blade
001A1431593 1
31 strengthen tendon 001A1301394 1
32 outlet grill hold middle 001A1231180 1
33 mini fan blade 001A1431599 1
34 cover 001A0100329 1
35 display panel 001A1431586 1
36 Airflow oriented board affix 001A1431827 3
37 curving connecting rod 001A1431598 1
38 receive panel 001A0600249 1
39 Indicator light base 001A1431587 1
40 Motor bracket 001A1301133 2
41 stepping motor 001A3000107 2
42 fixing layering 001A1301396 1
43 Drain pan 001A1233191 1
44 Evaporator left holder 001A1301400 1
45 Evaporator assembly 001A0400069 1
46 plate assy left 001A1101099 1
47 left wallboard 001A1101103 1
48 assistant drain pan 001A1231192 1
49 cover assy 001A1231182 1
50 back framework 001A1101098 1
51 Evaporator right holder 001A1301401 1
52 Remote Controller 0010400256 1
EXPLODED VIEWS & PARTS LISTS
