Haier AC36NACAAA [72/87] Exploded views parts lists
![Haier AC36NACAAA [72/87] Exploded views parts lists](/views2/1807752/page72/bg48.png)
HCFU-36H03 HCFU-42HC03 Part list of indoor unit
No. Name of parts Part specialized code QTY.
Remark
1 inlet grill assy 001A1231278 3
2 air filter 001A2400108 3
3 front panel assy 001A1101167 1
4 pad 001A17341009 1
5 Eletrical box 001A13011280 1
6 Eletrical box cover 001A1301379 1
7 PCB 0010400407 1
8 transformer 001A3800066 1
9 capacitor 01A3600018 2
10 termonal block 001A4000151 1
11 Power line clip 001A5701062 1
12 environment temp. sensor indoor 001A3900159 1
13 motor bracket 001A1301580 4
14 scroll case right 001A1301582 2
15 drain pan assy 001A1200325 1
16 mounting plate 001A1101172 1
17 air pipe 001A0500403 1
18 liquid pipe 001A0500404 1
19 partition plate 001A1301588 1
20 plate assy right 001A1301577 1
21 right wallboard 001A1301579 1
22 Ornamental plate right 001A1231277 1
23 left scroll case 001A1301574 2
24 centrifugal fan 01A2331071 4
25 motor bracket 001A1301581 2
26 Indoor fan motor 001A3000172 2
27 left wallboard 001A1301578 1
28 ornamental plate
left 001A1231276 1
29 Pipe temp. sensor indoor 001A3900006 1
30 Indicator light cover 001A1431878 1
31 receive panel 0010400410 1
32 ornamental plate of panel(left) 001A1231279 1
33 middle ornamental plate 001A1231280 4
34 Long blade assy 001A1101169 1
35 fixing bracket left 001A1431800 1
36 left fixing bracket 001A0100431 1
37 left top cover assy 001A1231272 1
38 front top cover assy 001A1231274 3
39 Ornamental plate of panel right 001A1231281 1
40 outlet grill hold middle 001A0100435 3
41 top cover assy 001A1231275 3
42 long blade
001A1101170 1
43 outlet grill hold right 001A0100432 1
44 right top cover assy 001A1231273 1
45 fixing bracket right 001A1431746 1
46 prompting pole 001A1443745 1
47 Synchromotor 001A3000198 1
48 Remote Controller 0010400256 1
49 Heat insulation pipe1 001A1734260 1
50 plate assy left 001A1301575 1
51 evaportor 0010700388 1
52 Rear guard plate 001A1101171 1
EXPLODED VIEWS & PARTS LISTS
