17
Dual bevel compound mitre saw 1131
INTRODUCTION
• This tool is intended as a stationary machine for
performing lengthways and crossways straight cuts in
wood or similar materials; also possible are horizontal
mitre angles of 45° (left side) to 45° (right side) as well as
vertical bevel angles of 45° (left side) to 45° (right side)
• This tool is not intended for professional use
• Read and save this instruction manual 2
TECHNICAL DATA 1
TOOL ELEMENTS 3
A Switch handle
B Locking pin for transport
C Safety lever
D Transport handle
E Support bar
F Mounting holes
G Dust bag
H Clamp for mounting workpiece
J Fence
K Locking screw (mitre angles)
L Mitre angle indicator
M Locking knob (bevel angles)
N Locking pin for right bevel angles
P Bevel angle indicator
Q On/o switch
R Hex key
S Protective guard
T Spindle-lock button
V Table insert
W Hex key
P1 Screw for adjusting 90° blade alignment
P2 Screw for adjusting bevel angle (left)
P3 Screw for adjusting bevel angle (right)
P4 Screw for adjusting bevel angle indicator
J1 Locking screw for fence extension
J2 Hex screws for adjusting fence (4x)
L1 Screw for adjusting mitre angle indicator
R1 Cover plate screw
R2 Blade bolt
R3 Flange
H1 Clamp support hole
H2 Knob for fastening clamp
H3 Knob for adjusting clamp
H4 Clamping knob
SAFETY
GENERAL SAFETY INSTRUCTIONS
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury. Save
all warnings and instructions for future reference. The
term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use an earth leakage circuit breaker.
Use of an earth leakage circuit breaker reduces the risk
of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on the
switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
