CS1822 / CS1824 User Manual
4
Requirements
Console
An HDMI monitor capable of the highest possible resolution
A USB mouse
A USB keyboard
Speakers
Computers
The following equipment must be available on each computer:
An HDMI port
A USB Type A port
An Audio port
Operating Systems
Windows
Mac
Linux
Cables
To guarantee video quality, we recommend using only ATEN HDMI KVM
cables. Two (CS1822) or four (CS1824) cables are provided with this package.
Note: The quality of the display is affected by the quality of the cables.We
recommend the total length from the source to the monitor to not exceed
6 meters (3 meters between the PC and the KVM switch. 3 meters
between the KVM switch and the monitor). If you need additional
cables, please contact your dealer to purchase ATEN approved cables.
