Chapter 2

Hardware Setup

Cable Connections

To set up your installation, refer to the installation diagram on the following

page (the numbers in the diagram on page 11 correspond to the steps below),

and do the following:

1. To prevent damages from power surges or static electricity, ground the unit

by connecting one end of a grounding wire to the grounding terminal, and

the other end of the wire to a suitable grounded object.

Note: 1. The grounding wire is not included in the package. Contact your

dealer for the appropriate cable.

2. Make sure the computers and devices that the unit connects to are

also properly grounded.

2. Plug your USB keyboard and USB mouse into the USB console ports

located on the unit’s rear panel.

3. Plug your monitor into the HDMI console port located on the unit’s rear

panel and power it on.

4. Plug your speakers into the console speaker jack located on the unit’s front

panel. Audio cable needs to be connected on the CPU side for this

connection to work.

1. Important safety information regarding the placement of this

device is provided on page 37. Please review it before

proceeding.

2. To prevent damage to your installation from power surges or

static electricity. It is important that all connected devices are

properly grounded.

3. Make sure that power to all the devices you will be installing has

been turned off. You must unplug the power cords of any

computers that have the Keyboard Power On function.
