Chapter 4. Hotkey Operation

port’s keyboard operating platform configuration so that the PC compatible

keyboard emulates the Mac or Sun keyboard. The procedure is as follows:

1. Bring the KVM focus to the port you want to set.

2. Invoke HSM (see page 20).

3. Press and release the appropriate Function key (see table below). After

completing this procedure, you automatically exit HSM.

List Switch Settings

To see a listing of the current switch settings, do the following:

1. Open a text editor or word processor and place the cursor in the page

window.

2. Invoke HSM (see page 20).

3. Press and release [F4] to display the settings.

Mouse Emulation Control

To enable/disable mouse emulation, do the following:

1. Invoke HSM (see page 20

2. Press [M].

Mouse Port Switching

Mouse Port Switching allows you to switch ports using mouse wheel button

(clicked twice). For Mouse Port Switching to work, Mouse Emulation must be

enabled. To enable/disable mouse port switching, do the following:

1. Invoke HSM (see page 20).

2. Press [W].

Function Key Operation

[F1] Sets the SPC mode so that it can work under special

operating systems as a standard (104 key) keyboard.

[F2] Enables Mac keyboard emulation, see page 29, for details.

[F3] Enables Sun keyboard emulation, see page 29, for details.

[F10] Enables Windows keyboard emulation.
