31
Chapter 6
The Firmware Upgrade Utility
The Windows-based Firmware Upgrade Utility (FWUpgrade.exe) provides a
smooth, automated process for upgrading the CS1822 / CS1824’s firmware.
The Utility comes as part of a Firmware Upgrade Package that is specific for
each device. New firmware upgrade packages are posted on our website as new
firmware revisions become available. Check the website regularly to find the
latest packages and information relating to them:
http://www.aten.com/global/en/support-and-downloads/downloads/
Before You Begin
To prepare for the firmware upgrade, do the following:
1. From a computer that is not part of your KVM installation, go to the
ATEN Support & Download site and choose the model name that relates to
your device (CS1822 / CS1824) to get a list of available Firmware
Upgrade Packages.
2. Choose the Firmware Upgrade Package you want to install (usually the
most recent), and download it to your computer.
3. Disconnect the CS1822 / CS1824 from your KVM installation and power
it off. Connect the USB cable’s Type A USB connector to a USB port on
your computer.
4. At the other end of the USB cable, connect the USB Type B connector to
the Type B USB port in the Port 1 KVM section.
Note: The USB cable’s USB Type B connector can be connected to any
KVM port section, but the Port Selection pushbutton in Step 5,
below, must be Port 1.
5. Press and hold the Port 1 selection pushbutton. While holding the button,
connect the power adapter to the CS1822 / CS1824 to enter Firmware
Upgrade Mode. The front panel LEDs flash together to indicate Firmware
Upgrade Mode is in effect.
