Chapter 4

Hotkey Operation

The CS1822 / CS1824 provides an extensive, easy-to-use, Hotkey function that

makes it convenient to control and configure your KVM installation from the

keyboard. Hotkeys provide asynchronous (independent) switching of the

KVM, USB hub and audio focus. If you wish, you can give one computer the

KVM console focus, another the USB hub focus and the other two the audio

focus.

Hotkey Port Switching

All port switches begin with tapping the [Scroll Lock] key twice.

Note:  If using the Scroll Lock key conflicts with other programs running

on the computer, the [Ctrl] key can be used instead. See Alternate

Port Switching Keys, page 21, for details.

 There are two audio mixer functions that will alter the audio port

switching function described in the following sections. Refer to

Stereo Audio Mixer on page 24 for more information.

Cycling Through the Ports

Hotkey Action

[Scroll Lock] [Scroll

Lock] [Enter]

Brings the KVM, USB hub, and audio focus from the port that

currently has the KVM focus to the next port on the installation

(CS1822: 1 to 2; 2 to 1. CS1824: 1 to 2; 2 to 3; 3 to 4; 4 to 1).

[Scroll Lock] [Scroll

Lock] [K] [Enter]

Brings only the KVM focus from the port that currently has it to

the next port on the installation. The USB and audio focus

remain where they are.

[Scroll Lock] [Scroll

Lock] [U] [Enter]

Brings only the USB hub focus from the port that currently has

it to the next port on the installation. The KVM and audio focus

remain where they are.

[Scroll Lock] [Scroll

Lock] [S] [Enter]

Brings only the audio focus from the port that currently has it

to the next port on the installation. The KVM and USB hub

focus remain where they are.
