Aten CS1824 [15/52] Chapter 1 introduction

Chapter 1. Introduction

No. Component Description

1 RJ-11 Serial Port Connect an RJ-11 to DB-9 cable to this port for RS-232 serial

commands.

2 Console Ports Section The cables from your HDMI monitor, USB keyboard, USB

mouse, speakers and USB peripherals* plug in here. Each

connector is marked with an appropriate icon to indicate itself.

*This USB 3.1 Gen 1 port features 5 Gbps data transfer rates

for compatible USB peripherals.

3 KVM Ports Section The cables that link the switch to your computers plug in here.

Each KVM port section is comprised of a speaker jack, a USB

Type B socket and an HDMI port.

4 Grounding Terminal The grounding wire (used to ground the unit) attaches

here.

5 Power Jack The power adapter cable plugs into this jack.
