CS1822 / CS1824 User Manual

N-Key Rollover Keyboard Supporting Function

Enabling N-key Rollover allows up to 15 simultaneous keystrokes. To enable/

disable N-key Rollover, do the following:

1. Invoke HSM (see page 20).

2. Press [K] [Enter].

Power-on Detection

To turn on/off power-on detection, do the following:

1. Invoke HSM (see page 20).

2. Press [E].

Restore Default Settings

To reset the CS1822 / CS1824 to its default Hotkey settings, do the following:

1. Invoke HSM (see page 20).

2. Press [R] [Enter].

All the Hotkey settings return to the factory default settings.

Stereo Audio Mixer

Stereo audio mixer is a mode function that mixes up to two audio sources and

output the mixed audio (to the speakers).

Note: HDMI audio mixing is unavailable, use audio cable connections for

audio mixing.

There are two ways to mix audio with two different hot keys:

Single Focus Audio Mixing Mode

This mode fixes one audio source to a port while letting the second audio

source* to combine with the fixed audio source, and mixes them as the audio

output, see the examples below:

 If the audio source is fixed on Port 2, Port 1 and Port 2 audio sources are

mixed up as a an audio output when the KVM focus is on Port 1.

 If the audio source is fixed on Port 3, Port 1 and Port 3 audio sources are

mixed up as a an audio output when the KVM focus is on Port 1.
