CS1822 / CS1824 User Manual
14
Mouse Switching
For mouse port selection: Double-click the scroll wheel of your USB mouse to
cycle through the ports.
Note: 1. Mouse switching is only supported by USB 3-key scroll wheel mice.
2. Mouse switching is disabled by default. See Hotkey Setting Mode
(HSM), page 20, to enable mouse switching.
3. Mouse switching is only supported when Mouse Emulation is
enabled.
Hotkey Switching
For Hotkey port selection: All port switches from the keyboard begin by
pressing the Scroll Lock key twice. Regarding details of the Hotkey
parameters, see Hotkey Operation, page 17.
RS-232 Commands
For RS-232 port selection: Enter the correct command and control to switch
port. Regarding details of the RS-232 command and control, please refer to the
CS1822-CS1824 RS-232 Command User Manual.
Hot Plugging
The CS1822 / CS1824 supports USB hot plugging – components can be
removed and added back into the installation by unplugging their cables from
the USB hub ports without the need to shut the unit down.
Powering Off and Restarting
If it becomes necessary to power off the CS1822 / CS1824 unit, before starting
it back up, you must do the following:
1. Shut down all the computers that are attached to the switch.
2. Unplug the switch’s power adapter cable.
3. Wait for 10 seconds and replug the switch’s power adapter cable.
4. Once the switch is powered up, power on the computers.
