Chapter 3. Basic Operation

Port ID Numbering

Each KVM port section on the CS1822 / CS1824 switch is assigned a port

number (respectively, 1 to 2 or 1 to 4). The port numbers are marked on the rear

panel of the switch (see page 7 for details).

The Port ID of a computer is derived from the KVM port number it is

connected to. For example, a computer connected to KVM port 2 has a Port ID

of 2.

The Port ID is used to specify which computer gets the KVM, USB peripheral,

and audio focus with the Hotkey port selection method (see page 18 for

details).

Alternative Manual Port Selection Settings

When Hotkey Setting Mode has been activated, pressing [S] will invoke the

alternative front panel pushbutton manual port selection functions, as

explained below:

 Press a port selection pushbutton once to bring only the KVM focus to the

computer attached to its corresponding port.

 Press a port selection pushbutton twice to bring the audio focus to the

computer attached to its corresponding port.

 Press and hold a port selection pushbutton for more than 2 seconds to

bring the KVM, audio and USB focus to the computer attached to its

corresponding port.

 Press and hold port selection pushbuttons 1 and 2 for more than 2 seconds

to start Auto Scan Mode, see page 19 for details.
