Chapter 5. Configuration

Remote Console

This section provides remote console related preference options.

Remote Console Preview

The preview in this screen shows a snapshot of the server’s display as follows:

Clicking Refresh updates the snapshot of the remote display.

Telnet Viewer

If the Serial Console is enabled and a user has telnet access rights, then the

“Open Telnet Client” button will appear on the Remote Console page. Click

this button to launch the built in telnet client AP.
