RCM KVM over IP Switch User Manual
4
Easy-to-Use Interface
Browser-based GUIs offer a unified multilanguage interface to minimize
user training time and increase productivity
Multiplatform client support (Windows, Mac, Linux, Sun)
Multibrowser support (IE, Firefox, Safari, Opera, Chrome)
Browser-based UI in pure Web technology allows administrators to
perform administrative tasks without requiring pre-installed Java software
Full-screen or sizable and scalable virtual remote desktop
Magic Panel with configurable function for quick launch
Advanced Security
Smart card/CAC reader support
External authentication support: RADIUS, LDAP, LDAPS and MS Active
Directory
Supports TLS 1.2 data encryption and RSA 2048-bit certificates to secure
users logging in from browsers
Flexible encryption design allows users to choose any combination of 56-
bit DES, 168-bit 3DES, 256-bit AES, 128-bit RC4 or Random for
independent keyboard/mouse, video, and virtual media data encryption
Supports IP/MAC filter
Supports password protection
Private CA
Virtual Media
Virtual media enables file applications, OS patching, software installation
and diagnostic testing
Works with USB-enabled servers at OS and BIOS level
Supports USB 1.1 and USB 2.0 DVD/CD drives, USB mass storage
devices, PC hard drives, folders and ISO images
