RCM KVM over IP Switch User Manual

vii

RCMHD101U

 1 RCMHD101U KVM over IP Switch

 1 KVM cable (HDMI, USB, audio)

 1 USB Type-A to USB Mini-B cable

 1 power adapter

 1 mounting kit

 1 foot pad set (4 pcs)

 1 user instructions
