RCM KVM over IP Switch User Manual
6
Supported Video Resolutions
Note: The above table lists the device’s supported video resolutions by
default. For further supporting of other resolutions, please contact your
dealer.
Resolutions
RCMVGA101 / RCMDVI101 RCMDP101U / RCMHD101U
4096 x 2160 @ 30 Hz ●
3840 x 2160 @ 30 Hz ●
2560 x 2048 @ 30 Hz ●
2560 x 1600 @ 30 Hz ●
2560 x 1440 @ 30 Hz ●
1920 x 1200 @ 60 Hz ● ●
1920 x 1080 @ 60 Hz ● ●
1680 x 1050 @ 60 Hz ● ●
1600 x 1200 @ 60 Hz ● ●
1600 x 900 @ 60 Hz ● ●
1440 x 900 @ 60 Hz ● ●
1400 x 1050 @ 60 Hz ● ●
1360 x 768 @ 60 Hz ●
1280 x 1024 @ 60 Hz ● ●
1280 x 1024 @ 75 Hz ●
1280 x 960 @ 60 Hz ● ●
1280 x 720 @ 60 Hz ● ●
1152 x 864 @ 75 Hz ●
1024 x 768 @ 60/70 Hz ● ●
1024 x 768 @ 75/85 Hz ●
800 x 600 @ 56/60 Hz ● ●
800 x 600 @ 72/75/85 Hz ●
720 x 400 @ 70 Hz ● ●
640 x 480 @ 60 Hz ● ●
640 x 480 @ 72/75/85 Hz ●
