Chapter 1. Introduction
5
Virtual Remote Desktop
Windows Client — remote desktop application on Windows PC for real-
time operation of the server / PC connected.
Java Client — remote desktop application on non-Windows PC for real-
time operation of the server / PC connected.
Web Client — browser-based remote desktop application, utilizing HTML
5, on any PC for real-time operation of the server / PC connected.
Note: 1. For Web Client’s HTML-5 features to be fully supported, it is
recommended to use IE, Firefox, Chrome, Opera, Edge, or Safari.
2. For optimal performance of Web Client’s HTML-5 features,
make sure your browser and CN9000/CN9600/CN9950’s
firmware is of the latest version.
Video quality and video tolerance can be adjusted to optimize data transfer
speed; monochrome color depth, threshold and noise settings can be
adjusted for compression of the data bandwidth in low bandwidth
situations
Full-screen video display or scalable video display
Message Board for communication among remote users
On-screen keyboard with multilanguage support
Mouse DynaSync
TM
— automatically synchronizes the local and remote
mouse movements
Supports Exit Macros
BIOS-level access
