RCM KVM over IP Switch User Manual
2
In addition, the RCM KVM over IP Switch can also be used to integrate the
compatible non-IP-based ATEN KVM switches and/or LCD consoles to
provide them with over-IP capabilities, such as for CS1768 and/or CL3800.
Features and Benefits
Hardware
Compact and slim design for space usage optimization
Equipped with FPGA graphics processor for better image quality and
enhanced fps throughput for a crisp video display
Provides over-IP capability to KVM switches / LCD consoles that do not
have over-IP functionality.
Local console provides USB keyboard and mouse support
A USB Mini-B port on the front panel serves as a laptop USB console
(LUC) port
Two 10/100/1000 Mbps NICs for redundant LAN or dual IP operation
Dual power supply for power backup
Supports multiplatform server environments: Windows, Mac, Sun, Linux
and VT100-based serial devices
Virtual media support
High video resolution — up to 1920 x 1200 @ 60Hz and 4096 x 2160 @
30 Hz for both local and remote consoles for RCMVGA101 /
RCMDVI101 and RCMDP101U / RCMHD101U, respectively
Audio support — microphone and speakers are supported on the local and
remote console
Note: 1. For the list of compatible KVM switch models, please refer to the
Compatible Products section on the product web page.
2. Since there are a large number of keyboards/mouses with
functions specifically designed for OS other than Windows, they
may not be compatible and may have compatibility issue.
