RCM KVM over IP Switch User Manual
vi
Package Contents
Check to make sure that all the components are in working order. If you
encounter any problem. Please contact your dealer.
RCMVGA101
1 RCMVGA101 KVM over IP Switch
1 KVM cable (SPHD to VGA, PS/2, USB)
1 USB Type-A to USB Mini-B cable
1 power adapter
1 mounting kit
1 control terminal block
1 foot pad set (4 pcs)
1 user instructions
RCMDP101U
1 RCMDP101U KVM over IP Switch
1 DisplayPort cable
1 USB Type-A to USB Type-B cable
1 USB Type-A to USB Mini-B cable
1 power adapter
1 mounting kit
1 control terminal block
1 foot pad set (4 pcs)
1 user instructions
RCMDVI101
1 RCMDVI101 KVM over IP Switch
1 KVM cable (DVI-D, USB, audio)
1 USB Type-A to USB Mini-B cable
1 power adapter
1 mounting kit
1 foot pad set (4 pcs)
1 user instructions
