![Aten RCMDP101U [23/196] System requirements](/views2/1977520/page23/bg17.png)
Chapter 1. Introduction
7
System Requirements
Remote User Computers
Remote user computers (also referred to as client computers) are the ones the
users log into the switch with from remote locations over the Internet. The
following equipment must be installed on these computers:
The computers used to access the switch must have at least a P III 1 GHz
processor, with their screen resolution set to 1024 x 768. It is
recommended that your PC shall have P IV 2 GHz with at least 1 Gb of
RAM.
Browsers must support TLS 1.2 encryption.
A network transfer speed of at least 128 kbps is required.
For the Log Server, you must have the Microsoft Jet OLEDB 4.0 or higher
driver installed.
Servers
Servers are the computers connected to the switch via KVM cables. The
following equipment must be installed on these servers:
For USB KVM cable connections: a USB Type-A port and USB host
controller
For virtual media connection: an extra USB Type-A and USB host
controller
Cables
A KVM cable set to link the RCM KVM over IP Switch to a server or
KVM switch are provided with this package.
Custom KVM cable sets for RCM KVM over IP Switch are available in
various lengths, as shown in the table below:
Model Cable Type Length CS Part Number
RCMVGA101 PS/2-USB
VGA KVM
Cable
1.2 m 2L-5301UP
1.8 m 2L-5302UP
3.0 m 2L-5303UP
