9

Chain saw 0780
INTRODUCTION
• The power tool is intended for sawing wood such as
wooden beams, planks, branches, tree trunks, etc., and
for sawing of trees; cuts can be sawed with or across the
grain
• This tool is not intended for professional use
• Check whether the packaging contains all parts as
illustrated in drawing 2
• When parts are missing or damaged, please contact your
dealer
• Readthisinstructionmanualcarefullybeforeuse
andsaveitforfuturereference3
• Payspecialattentiontothesafetyinstructionsand
warnings;failuretofollowthesemayresultin
seriousinjury
TECHNICAl DATA 1
TOOl ElEmENTS 2
A Cover plate
B Locking knob
C Chain
D Chain bar
E Symbol for rotation and cutting direction
F Drive sprocket
G Fastening bolt
H Guide ns for chain bar
J Chain tensioning peg
k Chain tensioning knob
l Oil outlet
m Oil reservoir cap
N Minimum mark
P Cord restraint
Q Safety switch
R Trigger switch
S Activation lever for kickback brake (hand guard)
T Front handle
U Rear handle
V Metal gripping teeth
W Ventilation slots
X Chain guard
Y Storage rail (screwsnotsupplied)
Z Storage hook
SAFETY
GENERAl SAFETY INSTRUCTIONS
WARNING!Readallsafetywarningsandall
instructions. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury. Save
allwarningsandinstructionsforfuturereference. The
term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) WORk AREA SAFETY
a) Keepworkareacleanandwelllit. Cluttered or dark
areas invite accidents.
b) Donotoperatepowertoolsinexplosive
atmospheres,suchasinthepresenceofflammable
liquids,gasesordust. Power tools create sparks which
may ignite the dust or fumes.
c) Keepchildrenandbystandersawaywhileoperating
apowertool. Distractions can cause you to lose control.
2) ElECTRICAl SAFETY
a) Powertoolplugsmustmatchtheoutlet.Never
modifythepluginanyway.Donotuseanyadapter
plugswithearthed(grounded)powertools.
Unmodied plugs and matching outlets will reduce risk of
electric shock.
b) Avoidbodycontactwithearthedorgrounded
surfacessuchaspipes,radiators,rangesand
refrigerators.There is an increased risk of electric
shock if your body is earthed or grounded.
c) Donotexposepowertoolstorainorwetconditions.
Water entering a power tool will increase the risk of
electric shock.
d) Donotabusethecord.Neverusethecordfor
carrying,pullingorunpluggingthepowertool.Keep
cordawayfromheat,oil,sharpedgesormoving
parts. Damaged or entangled cords increase the risk of
electric shock.
e) Whenoperatingapowertooloutdoors,usean
extensioncordsuitableforoutdooruse. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f) Ifoperatingapowertoolinadamplocationis
unavoidable,useanearthleakagecircuitbreaker.
Use of an earth leakage circuit breaker reduces the risk
of electric shock.
3)PERSONALSAFETY
a) Stayalert,watchwhatyouaredoinganduse
commonsensewhenoperatingapowertool.Donot
useapowertoolwhileyouaretiredorunderthe
influenceofdrugs,alcoholormedication. A moment
of inattention while operating power tools may result in
serious personal injury.
b) Usepersonalprotectiveequipment.Alwayswear
eyeprotection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Preventunintentionalstarting.Ensuretheswitchis
intheoff-positionbeforeconnectingtopower
sourceand/orbatterypack,pickinguporcarrying
thetool. Carrying power tools with your nger on the
switch or energising power tools that have the switch on
invites accidents.
d) Removeanyadjustingkeyorwrenchbeforeturning
thepowertoolon. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e) Donotoverreach.Keepproperfootingandbalance
atalltimes. This enables better control of the power tool
in unexpected situations.
f) Dressproperly.Donotwearlooseclothingor
jewelry.Keepyourhair,clothingandglovesaway
frommovingparts. Loose clothes, jewelry or long hair
can be caught in moving parts.
