Partner PSKL72B [7/40] Assembly

ASSEMBLY (starts at page 35)

DESCRIPTION (starts at page 35)

OPERATION (starts at page 35)

ENGLAND

Before you start working, make sure to remove any objects or obstacles that may have been left on the lawn. The operator is responsible for the safety of other people

in the working area.

(starts at page 35)

(starts at page 36)

1 Accelerator lever 5 Belt housing 9 Starter handle 13 Reducer

2 Wheels control lever 6 Deck 10 Wheel 14 Fuel tank

3 Control rod 7 Oil filter cap 11 Handle 15 Mowing bar

4 Clutch lever 8 Oil drain plug 12 Spark plug

ARRANGEMENT OF MOTOR

For the setting of the engine, it is necessary to follow the instructions given in the maintenance manual issued by the manufacturer of the engine

The machine working controls are so as follows:

- Accelerator lever (1) on the control panel.

- Wheels control lever (2) on the right handle.

- Control rod (3) for the engagement and disengagement of the bar moweron

the right side of the deck.

- Clutch lever (4) on left handle. This handle must be kept pressed while using

the machine; if released the machine will stop working.

The equipment coupling and wheels controls are indipendent.

ENGINE STARTUP

CAUTION:- 0.6l Oil must be added to the engine before use.

Once the machine has been set up properly, start the engine as follows:

a)If the engine is cold, position the accelerator lever (1) on START.

- Position the wheel control lever (2) into position stop

- Position the control rod engagement/disengagement (3) into position stop

b)Grip the starting handle (9) and pull the starter rope gently until you feel the re-

sistance caused by compression. Release the handle; then give the starter rope

a sharp tug.

For further information and explanations, read carefully the user instruction manual

of the engine.

WHEN THE ENGINE RUNS: stand behind the mower's handle, press slightly the

control handle (4) and push slowly forward the control rod (3) until the engement,

then push it deeply. Press deeply the control handle and keep it pressed.

The bar mower will start working.

At this point release the wheels control lever (2) until on start, the machine moves

forward; now you can start your work.

STOP: release the clutch lever

SAFETY RULES

Training

a)Persons under 16 years of age and persons who are

not acquainted with the user instructions must not use

the bar mower.

b)The operator is responsible for the safety of other people

in the working area. Keep children and domestic animals

at a safe distance when the mower is in use.

c)The risk of injury to hands and/or feet due to the mowing

unit is very high.

d)This machine may be used exclusively for cutting natural

grass. Its use is not allowed for other purposes (e.g., for

flattening out bumps in the ground, such as mole-hills

or ant- hills).

e)Work only when there is sufficient light.

f)Before you start cutting the lawn, make sure to remove

any objects or obstacles that might be present. While

you are using the mower, keep your eyes open for the

possible presence of such objects that may have been

left on the lawn.

Setting up and operating the aspirator

a)When using the bar mower machine, wear strong

footwear (boots or heavy shoes) and long trousers.

b)Before starting mowing, make sure that the mowing

bar is properly fastened and the protective sheath has

been removed.

c)During engine startup, under no circumstances lift up

the machine.

d)Turn off the engine and disconnect the cap of the spark

plug whenever:

removing the protection devices

transporting, lifting or displacing the machine from the

working area

carrying out maintenance or cleaning

carrying out any operation on the cutting tools

leaving the bar mower machine unattended.

CAUTION! The tools keep turning for a few seconds even

after the engine has been turned off.

e)CAUTION! The fuel is highly inflammable:

keep the fuel only in the fuel cans provided for that

purpose

pour the fuel into the tank only in the open air and make

sure not to smoke

fill up the fuel tank before starting the engine. Under no

circumstances open the fuel tank cap or add petrol when

the engine is running or when it is still hot

if the petrol has overflowed, do not under any circum-

stances start up the engine. Take the machine out of

the area where the fuel has been spilt and avoid any

source of possible ignition until the petrol fumes have

dissipated

replace the fuel tank cap and tighten it down firmly.

f)The machines with internal combustion engines must

never be operated in closed environments on account

of the danger of carbon monoxide poisoning.

g)The safety distance, which is set by the length of the

handle, must always be kept. Furthermore, when the

aspirator is working, never run; you must always walk.

h)Particular precautions must be taken when using the

bar mower on slopes or downhill stretches:

use appropriate antislip footwear

watch where you put your feet

always move sideways with respect to the slope; never

move uphill or downhill

take great care when changing direction

do not work on excessively steep slopes.

i)Never use the bar mower with faulty guards or protections

or without safety devices installed and in proper order.

j)For reasons of safety, the engine must never exceed the

number of revs (r.p.m.) indicated on the data plate.

k)Take care when starting the engine and make sure to

follow the user instructions. When the engine is turning,

it is absolutely indispensable to prevent anybody from

approaching the front of the machine.

l)Whenever leaving the bar mower unattended, first make

sure to turn off the engine.

m)Should the mowing bar have hit against an obstacle,

turn off the engine, remove the spark plug cap, and

then check the bar thoroughly. Should the bar not work

properly, have it checked by a qualified technician.

Maintenance and storage

a)Make sure that all nuts, bolts and screws are kept well

tightened down so as to work in conditions of perfect

safety.

b)Never leave the machine with fuel in the tank where the

fuel vapours could reach naked flames or sparks.

c)Give the engine enough time to cool off before putting the

equipment in any narrowly enclosed environment.

d)Keep the engine, silencer, and petrol tank free from

grass, leaves and excess lubricant in order to reduce

the danger of fire.

e)For safety reasons, make sure to replace worn-out or

damaged parts in due time.

f)Should you drain off the fuel tank in order to store the

bar mower away for the winter, make sure to carry out

this job in the open air.

g)Install the cutting tools following the corresponding

instructions and use exclusively tools bearing the Ma-

nufacturer's or Supplier's name or trademark and the

reference number.

h)To protect your hands during disassembly or assembly of

the cutting tools, wear suitable protective gloves.

Assemble handles as shown with bolts and screws supplied.

Assemble clutch lever, cables and control plate as shown with bolts and screws supplied.
