DETERMINING BATTERY TYPE AND SPECIFICATIONS

Prior to connecting any battery to your Pilotage Simplex Competition it is essential that you determine the type of battery and its

specications prior to charging it. Required information about your battery pack can be determined by examining the label and any

instructions that might accompany the battery pack.

1. Type – Is the battery: Nickel-Cadmium (NiCd), Nickel-Metal Hydride (NiMH), Lithium Polymer (Li-pol/Lipo) or Lithium Ferrite

Nanophosphate (LiFe/A123)

2. Capacity: The capacity of your pack usually can be found on the battery label and is usually denominated in mAh. Never charge a

battery if you are uncertain of the capacity!!

3. Voltage: If not explicitly listed on your battery back you can determine the pack’s voltage in the following manner:

• NiMH/NiCd – number of cells connected in serial multiplied by 1.2V, for example a pack of 6 Sub C NiMH/NiCd cells will have a

rated voltage of 7.2V.

• Li-Pol – Number of cells connected in serial multiplied by 3.7V, for example a pack of 3 Li-Pol cells in serial will a have a rated

voltage of 11.1V.

• Li-Fe (A123) – Number of cells connected in serial multiplied by 3.3V, for example a pack of 3 Li-Fe cells will have a rated voltage of

9.9V.
