Pilotage Simplex-4 Competition RC12495 [34/70] Battery discharge

32

The time elapsed, capacity discharged, discharge current and battery voltage will be

displayed on the screen. During discharging, press the “Battery Type” button to view the

internal resistance of the battery pack.

In the cycling screen, press the “Enter” button to set the order of cycling and, use the “–“ or

“+” buttons to toggle between “Charge->Discharge” or “Discharge->Charge”. You cannot

change any other parameters in this screen. The charger will use the settings from the charge

and discharge screen, including battery cells, battery capacity, charge current, DeltaV and

discharge current. NiMH and NiCd batteries will be discharged to 1.0V/cell.

When the battery pack’s voltage reaches the cuto voltage, the charger will display “BATTERY

DISCHARGE COMPLETE” on the screen.

Press “Enter” to view total discharge time, discharge capacity, average discharge voltage

and nal voltage. Then press the “Battery Type” button to view the battery pack’s internal

resistance. Finally press the “Enter” button to return to the discharge screen.

DISCHG 1:10:30 3500

NM 10.200Va 7.200Vb

Cycling a NiMH/NiCd battery pack

From the main screen, while no text is ashing, keep pressing the “–“ or “+” button until “Cycle” appears in the charge function portion

of the menu.
