Button Functions

The charger has 4 buttons that are used to change and modify various charging functions.

Battery Type

Enter

+ –

• Press this button to change the battery chemistry while “Battery Type” eld is ashing on the main screen.

Press this button to exit setting any parameter while other elds are ashing.

• Press and hold this button from the main screen to view the input and output voltages.

• During charging/discharging process, press this button to view the battery resistance; press twice to view

the voltage of individual cells (Li-Pol/Li-Fe only).

• By pressing “–“ or ”+” you can decrease/increase the value of a parameter when it is ashing on the main screen.

• While on the main screen and no text is ashing, press – or + to select between charge, discharge, cycle or

storage mode.

• Turn on/o the backlight of LCD during charging and discharging.

• By pressing this button you can cycle through the parameters on the main screen.

• By holding this button you can start the charging or discharging process. Press this button during

charging or discharging to suspend the process.

INPUT = 13.75V

OUTPUT = 07.74V

CHARGE 0:47:53 2553

LP BAT.RES = 27mΩ

1 = 3.87V 2 = 3.87V

3 = 3.87V 4 = 3.87V

To display the actual input and battery voltages, rst connect your battery to the charger,

then press and hold the “Battery Type” button from the main screen until you see the voltages

are displayed. If the battery is not connected to the charger, only the input voltage will be

displayed.

Display Input and Battery Voltage

INPUT = 12.00V

OUTPUT = 07.00V
