Press and hold the “Enter” button to start the storage process. The charger will automatically

discharge the battery then recharge it to 50% of the capacity you set. During the storage

process, the current operation mode, time elapsed, capacity discharged/charged, current

and battery voltage will be displayed.

Storing a NiMH/NiCd battery pack

From the main screen, while no text is ashing, press” +” or “–“ to select storage mode. The special storage mode will discharge and/or

recharge your NiMH/NiCd battery so that it is in an optimal state for storage. Doing this will minimize the risk of battery damage due to

deep discharge if the battery is stored for a long period of time.

In the storage screen, you cannot set any parameters, the charger will use the settings from

the charge and discharge screen including battery cell count, capacity, charge current and

discharge current.

Press “Battery Type” to view the pack’s internal resistance, press “Battery Type” again to return

the working screen.

Once the storage process is complete, the charger will display “BATTERY STORAGE

COMPLETE” on the screen.

Press “Enter” to view the nal charge data, including total charge time, capacity, the battery’s

peak voltage and nal voltage. Press “Battery Type” to view the battery’s internal resistance.

Then press the “Enter” button again to return to the storage screen.

BATTERY CHECK

PLEASE WAIT...

DISCHG 0:01:30 45

NM 2.00A 10.494Vb

DISCHG 0:02:25 77

NM BAT.RES = 220mΩ

CHARGE 0:32:04 1800

NM 11.890Vp 11.867Vb

M01 NiMH STORAGE 8C

3600mAH C = 3.5A D = 6mV

BATTERY STORAGE

COMPLETE

CHARGE 0:01:20 45

NM 3.60A 11.200Vb
