www.pilotage-rc.com
27
CHARGING NIMH/NICD BATTERY PACKS
It is absolutely essential to select the correct battery type. ATTENTION: CHARGING BATTERIES WITH THE INCORRECT CHARGE SETTING
IS A FIRE HAZARD. BE SURE TO CHECK THE BATTERY TYPE PRIOR TO PROCEEDING.
In the main screen, while battery type is ashing, choose NiMH or NiCd using the “Battery Type” button. A NiMH battery will be used in
this section to demonstrate how to use the charger for these battery chemistries.
Charging NiMH/NiCd Battery Packs
M01 NiMH CHARGE 6C
3600mAH C=3.6A D=5mV
M01 NiCd CHARGE 6C
3600mAH C=3.6A D=15mV
When you choose the NiMH or NiCd battery type, the charger will enter NiMH/NiCd charging
mode.
Press the “Enter” button repeatedly until the battery cell count ashes. Use the “–“ or “+” to
change the cell count. Be sure to select the correct cell count. Selecting the wrong cell count
may cause the charger to miscalculate the safety voltage and disable the safety features of
this charger.
After the cell count is set, press the “Enter” button until battery capacity ashes. Use the “–“
or”+” button to set the correct capacity. Setting the wrong capacity may cause the charger
miscalculate the pack’s features and damage the battery.
M01 NiMH CHARGE 8C
3600mAH C=3.6A D=5mV
M01 NiMH CHARGE 8C
3600mAH C=3.6A D=5mV
M01 NiMH CHARGE 6C
3600mAH C=3.6A D=5mV
