CHARGE 0:00:25 5

LP BAT.RES = 41mΩ

CHARGE 0:05:20 62

LP 0.00A 12.600Vb

1 = 4.10V 2 = 4.00V

3 = 4.00V 4 = 0.00V

5 = 4.10V 6=4.00V

BATTERY CHARGE

COMPLETE

During charging, press the “Battery Type” button to view the battery resistance.

Press the “Battery Type” button again to view the voltage of individual cells. If your Li-Pol

battery has more than 4 cells, press “Battery Type” one more time to display the 5th and 6th

cells’ voltage. This is possible only if the balancing mode is on and the battery’s balancing

connector is connected to the charger.

After the charging process completes, the charger will display “BATTERY CHARGE

COMPLETE” on the screen. Press “Enter” to view charge time, charge capacity and battery’s

nal voltage. Then press “Battery Type” to view the battery’s internal resistance and press

“Battery Type” again to view the voltage of individual cells.

Finally press the “Enter” button to return to the charge screen. If you have any problem during charging, the charger will display error

messages. Please refer to the “Error Messages” section for detailed information.
