TROUBLESHOOTING
Problem Cause Solution
LCD panel does not illuminate and charger does not
turn on
Improper connection to power source Check polarity of connections to power source.
Power source not plugged in
Check if power source is turned on, plugged in and
operational.
Power source does not provide proper output power
Check input specications on charger and ensure that
they match the output specications on the power
supply.
Charger does not detect battery
Improper connection to charger Check polarity of connection to charger.
Li-Pol and Li-Fe is not connected to balancer
Remember that as a safety option, this charger will
not charge Li-Pol and Li-Fe batteries unless they are
connected to the balance charge adaptor when the
balance charge function is activated.
Battery capacity low after charging
Charge current too low
Check that the charge current is properly matched to
the capacity of the battery.
Battery damaged
Examine the state of the battery. If it shows any sign of
damage immediately cease using the battery.
Battery is old or capacity diminished by memory eect
(NiMH/ NiCd only)
NiCd/NiMH ONLY - the memory eect is diminishing
the capacity of your cells. Run a number of full charge/
discharge cycles to see if the capacity increases.
